Image preview - the first page of the document



>> Download 2H9-011 documenatation <<

Text preview - extract from the document

                                             Service Bulletin
 SB Number: SB 2H9-011_Revised issue                                                        Creation Date: 12/01/2012
 Subject:                Replacing/Re-assembling the Holder DU and Stay DU
 Model:                  FS-1028MFP/1128MFP/1030MFP/1130MFP/1035MFP/1135MFP

 Revision information: Affected models have been added.


The Holder DU and Stay DU will no longer be supplied as individual parts since the paper may feed a skewed,
when the adjustment is not performed after replacing one of the above mentioned parts individually. Therefore
please use the Parts holder DU assy SP (302FM94060), when replacing the Holder DU or Stay DU.




Above view of the machine
                                              Old condition                                             New condition

                                              Pulley MID                                Stay DU            Parts holder du assy SP




                                               Holder DU                         Shaft pulley




Parts
No. Old Parts                 New Parts         Description                                                Q'TY           Interchange- SP
    No.                       No.                                                                                         ability
                                                                                                           Old      New Old       New
1       ------------          302FM94060        PARTS HOLDER DU ASSY SP (*1)                               -        1     -       O       O
                              2FM94060
2       2FM21010              ------------      +HOLDER DU                                                 -        -     -       -       -
        5MVX861XB001
3     2FM21020           ------------  +STAY DU                                  -       -      -      -      -
      5MML821SD009
Part notes: (*1): This Assembly part contains the Holder DU (1 piece), the Stay DU (1 piece), the Shaft pulley_
                  302FM02421 (1 piece) and the Pulley MID_2FM02210 (2 pieces)


Classification          Entire stock rework       In-field modification at next visit        X No modification necessary
                                                                                          In-field modification by case
Field measure          When replacing the Holder DU and Stay DU, please use the Parts holder DU assy SP
                       (302FM94060). Do not replace the Holder DU and Stay DU individually. Under this condition,
                       a skewed feeding of the paper may occur.



KMIS Service Department, Kyocera Mita Europe                             Page 1 of 1                                          A324 / SB 2H9-011
