Image preview - the first page of the document
>> Download SB-2MH-0003-C006 documenatation <<
Text preview - extract from the document
(Page.1/3)
Service Bulletin Ref. No. 2MH-0003 (C006)
January 19, 2012
Firmware Upgrade (Main: Ver.002.005); DVD-ROM Upgrade
Subject (Ver.2.0 KM Version, UTAX/TA Version); Change to the Quick
Installation Guide
FS-1x30MFP-1x35MFP_v02.00.0010_(2012-01-11)
Model FS-1030MFP, FS-1130MFP, FS-1035MFP, FS-1135MFP
Topic
The main firmware, the DVD-ROM (KM version, UTAX/TA version) and the Quick Installation Guide were changed
for the Network TWAIN/WIA support.
Content of Changes
No. Change Details CTL FW
1 OEM support for Olivetti OEM settings are now supported for Olivetti. 575416 MAIN
Network TWAIN/WIA The Network TWAIN/WIA is now supported.
2 support *Please use DVD Ver.2.0 or later to enable the Network TWAIN/WIA 575070 MAIN
functions.
No Change Details Ver.
.
Korean support Korean Operation Guide and the FAX Operation Guide were added. 1.1
1 (KM version only)
Network TWAIN/WIA The TWAIN/WIA drivers were implemented and upgraded. 2.0
driver support TWAIN Driver 2.0.1114
2
WIA Driver (Network) 2.0.1114
The explanation was added to the Operation Guide.
Support for South The Operation Guide and the FAX Operation Guide for these countries were added: 2.0
3 America, Taiwan and Spanish (South America) Brazilian Portuguese (Brazil) French (Canada), Simplified
China (KM version only) Chinese, Traditional Chinese
For more details on other changes, please refer to the next pages.
Check Status Current
Program No. Ver. Remark
SUM Date Ver.
MAIN 2MH_2F00002005 - 002.005 2011/11/1 001.100 *1 New upgrade
MAIN 2MJ_2F00002005 - 002.005 2011/11/1 001.100 *2 New upgrade
ENGINE 2MH_1000001011 - 001.011 - - *3
ENGINE 2MK_1000001011 - 001.011 - - *4
SCANNER 2MH_1200001008 - 001.008 - -
Optional language Brazilian
2MH_81BR001004 - 001.004 - -
BR Portuguese
Optional language Korean
2MH_81KR001001 - 001.001 - -
KR (For KMKR)
FAX BOOT/APL 2H9_5500008001 - 008.001 - - *5
Supported models:
*1 FS-1030MFP, FS-1035MFP *2 FS-1130MFP, FS-1135MFP
*3 FS-1030MFP, FS-1130MFP *4 FS-1035MFP, FS-1135MFP
*5 FS-1130MFP, FS-1135MFP
For the KM sales companies, it is possible to download the firmware at the download center on the ESDC.net.
When upgrading the firmware or replacing a board, please upgrade all kinds of the firmware to the latest version at the same
time.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.2/3)
Service Bulletin Ref. No. 2MH-0003 (C006)
January 19, 2012
KMC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: Please upgrade the firmware when the phenomenon described above arises.
Serial Nos. of the Affected Machines:
Firmware: From the first production for Olivetti in December 2011
DVD-ROM VER1.1: From the first production for KMKR
DVD-ROM and Quick Installation Guide: From the December 2011 production for KMA South America*
*The above is the plan at the present moment. Please note that this information is subject to change.
No. Change Details CTL FW
Measures against the Hangul fonts in Korean Command Center looked corrupted.
illegible Korean 578067
3 Therefore, the magnification of the browser was set to 120% for TO-11-051
MAIN
Command Center
display Korean only.
608881
Measures against the The CF248 error occurred with a certain data. Therefore, this was
4 TP-11-166 MAIN
system error (CF248) corrected. #1316019
Prevention of the If the character codes 0x21, 0x52 and 0x21 (!R!) exist in
608887
5 prescribe mode entry series in the PCL5 data, the prescribe mode was unintentionally TP-11-046 MAIN
with a certain file entered and no data was printed after that. Therefore, this was NP-Z11006
corrected.
Measures against the 576987
Depending on the type of the report, print range adjustment might be
6 print range adjustment TP-090318 MAIN
reflected to the report. Therefore, this was corrected. NP-Z09067
failure
No. Change Details
The following drivers and utilities were upgraded in addition to the TWAIN/WIA driver as
explained on the page 1.
[For KM]
KX Printer Driver 5.3.1103
KM (XPS) Driver 1.2.2301
Novell NDPS 5.3.1103
KPDL mini-driver XP and later (Overseas) 8.1111 [11-11-2011]
KPDL mini-driver XP and later (Japanese) 8.1111 [2011-11-11]
Macintosh 10.4 and lower (Overseas) 8.1111 [11-11-2011]
Macintosh 10.5 and up (Overseas) 8.1111 [11-11-2011]
Drivers/Utilities Macintosh 10.4 and lower (Japanese) 8.1111 [2011-11-11]
1
upgrade Macintosh 10.5 and up (Japanese) 8.1111 [2011-11-11]
KMnet Viewer 5.3.2329a
[For UTAX/TA]
KX Printer Driver 5.3.1103
KM (XPS) Driver 1.2.2301
KPDL mini-driver XP and later 8.1111 [11-11-2011]
Linux 8.1111 [11-11-2011]
Macintosh 10.4 and lower 8.1111 [11-11-2011]
Macintosh 10.5 and up 8.1111 [11-11-2011]
NETWORK PRINT MONITOR 5.3.2329a
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.3/3)
Service Bulletin Ref. No. 2MH-0003 (C006)
January 19, 2012
No. Change Details
Network TWAIN/WIA
1 The descriptions on the Network TWAIN/WIA were added.
support
2 Catalan support The descriptions in Catalan were added.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
