Image preview - the first page of the document



>> Download SB-2MK-0001-B349 documenatation <<

Text preview - extract from the document

                                                                                                             (Page.1/1)

         Service Bulletin                                                         Ref. No.2MK-0001 (B349)
                                                                                          November 1, 2011
  Subject Disuse of the PARTS MOTOR FAN 40 SP
          FS-1030MFP, FS-1030MFP/DP, FS-1130MFP,
  Model   FS-1035MFP/DP, FS-1035MFP/SP, FS-1135MFP,
          FS-1135MFP/SP
Topic
The PARTS MOTOR FAN 40 SP was abolished after it was confirmed there is no problem in functionality.




            No.1
            abolished




                                                                                     Com pati-
         Old Part       New Part                                       Q'ty            bi lity
 No.       No.            No.                Description                                               Remarks
                                                                   Old New           Old New
        302H994280
  1                      ----         PARTS MOTOR FAN 40 SP        1          -       O     -
         2H994280




 KMC's Classification              Entire Stock Rework                        In-Field modification at next visit
                                   In-Field modification by case              No modification necessary
 Field Measure: No particular problem is expected.

 Serial Nos. of the Affected Machines: Planned from the October 2011 production




                                            KYOCERA MITA Europe B.V.
                                   European Service & Development Center (ESDC)
