Image preview - the first page of the document
>> Download A324_COM_0200_SB documenatation <<
Text preview - extract from the document
(Page.1/1)
Service Bulletin Ref. No. COM-0200 (A324)
[Service Information] October 5, 2010
Subject Note when replacing/reassembling HOLDER DU and STAY DU
FS-1300D, FS-1350DN, FS-1120D, FS-1320D, FS-1370DN,
Model
FS-1028MFP/KM-2810, FS-1128MFP/KM-2820
HOLDER DU (No.2) and STAY DU (No.3) are no more supplied as individual parts because adjustment is
necessary after assembling them.
If HOLDER DU/STAY DU must be replaced, please use the assembly parts (No.1) instead of them.
[Precaution] In case of replacing/reassembling HOLDER DU/STAY DU individually, the paper skew may occur
depending on adjustment.
STAY DU (No.3) -->
Individual part is not supplied.
SHAFT PULLEY (X)
PULLEY MID(Y)
HOLDER DU (No.2)
--> Individual part is not
supplied.
HOLDER DU ASSY (No.1)
Com pati
Old Part New Part Q'ty
No. Description bi lity SP Remarks
No. No.
Old New Old New
302FM94060 PARTS HOLDER DU
1 ------------ - 1 - O O *1
2FM94060 ASSY SP
2FM21010 Supply discontinuance
2 ------------ +HOLDER DU - - - - - as individual parts
5MVX861XB001
2FM21020 Supply discontinuance
3 ------------ +STAY DU - - - - - as individual parts
5MML821SD009
Parts with "O" indicates regular maintenance parts. "+" Mark at the head of the description means it is a components parts.
*1: Assembly parts that contains each 1 pce of HOLDER DU (No.2), STAY DU(No3), SHAFT PULLEY (X in the above figure:
302FM0242_) and 2 pcs of PULLEY MID(Y: 2FM0221_)
KMC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure:
Please use the assembly parts (No.1) if HOLDER DU (No.2) and STAY DU (No.3) must be replaced.
And, please don't remove HOLDER DU and STAY DU individually.
(Please don't reassemble them in the field.)
