Image preview - the first page of the document
>> Download SB-2LY-0005-C284 - Изменения конструкции documenatation <<
Text preview - extract from the document
(Page.1/5)
Service Bulletin Ref. No. 2LY-0005 (C284)
October 23, 2012
Conformity to the ErP Lot6 (Change of the Main Power Switch
Subject and the Control PWB, Firmware Upgrade)
--- For KDE, UTAX/TA and Olivetti only
FS-1120D_FS-1320D_05.00.0010_(2012-06-21)
Model FS-1120D, FS-1320D l:
KMC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure:
When replacing the parts in the machine conforming to the ErP Lot6, please make sure to use the parts
conforming to the ErP Lot6.
As for the current models, please use the old parts except the left cover (No.1) and the control PWB (No.12).
(Both of the new and the old parts of No.1 and No.12 can be used.)
(*) Please note that the error may appear or operation failure may occur if the parts in the wrong combination
are applied. For more details, please refer to [Operation list] on the page 3.
Serial Nos. of the Affected Machines: Please refer to the page 4.
Topic
In order to conform to the power consumption requirements during standby and OFF modes (Energy related-
Products Lot6) in EU countries, the main power OFF timer function (Note 1) was added by changing the main
switch, the control PWB and the neighboring parts and by upgrading the firmware. (For more details, please refer to
the following pages.)
(Note 1) It is a new function to automatically turn the main switch OFF after passing the certain time
since the last use of the machine.
The new product codes and the serial numbers were newly set up for the models with the main power OFF timer
function in order to conform to the ErP Lot6. (Please refer to the last page.)
Content of Changes
Exterior change: The following changes were made to relocate the main power switch from the machine left rear
side to the front of the right cover. Also, the switch was changed from the primary to the secondary power control.
- Left cover side : The space was filled and the CONN. CORD ASSY was changed due to disuse
of the main power switch.
- Right cover side: The KEY POWER was added, the right cover was changed, and the parts
such as the holder were added.
Inner change: - Right frame: The shape was changed in order to add the MOUNT PWB SW.
- The MOUNT PWB SW and the other parts such as the switch were added.
- Control PWB: The DC/DC converter was changed and the circuit breaker, etc. were added.
- Switching regulator: The relay circuit was added and the zero cross circuit was relocated.
Space filled by fitting the Shape change of the
Left cover (No.1) cover (No.2) left cover (No.1)
Disusing the main power
switch for the primary
power.
CONN.CORD ASSY (No.3) Change of the Switching
changed from the type with a regulator (No.4)
switch to the one without - Relay circuit added
switch
- Zero cross circuit
relocated
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
(Page.2/5)
Service Bulletin Ref. No. 2LY-0005 (C284)
October 23, 2012
HOLDER KEY SW (No.6)
KEY POWER (No.8) added added
Change of the
right cover (No.5)
SPRING FUSER (No.7)
added
Cutout added
Shape change of
the right frame
Barring hole
added
MOUNT PWB SW (No.9) added
Screw (No.10)
added
P.W.BORD ASSY SWITCH (No.11) added
(Including the PWB, the main power switch
for the secondary power and the wires)
Connector of the P.W.BORD ASSY
SWITCH
Control PWB (No.12): - Change of the DC/DC converter
- New circuit breaker, etc.
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
(Page.3/5)
Service Bulletin Ref. No. 2LY-0005 (C284)
October 23, 2012
[Operation List]
Old control PWB (No.12)
Switching Main Engine
Main Unit Operation Remarks
Regulator Firmware Firmware
Current Old Old Old Old operation Correct combination
model Old Old New Old operation
unconforming Old New Old Old operation
to the ErP Old New New Old operation
Service call error C6400 (zero cross signal error)
Lot6 New Old Old X
appears when machine enters the sleep mode.
New Old New Old operation
Service call error C6400 (zero cross signal error)
New New Old X
appears when machine enters the sleep mode.
New New New Old operation
- Service call error C6400 (zero cross signal error)
New model appears when machine enters the sleep mode.
New Old Old X
conforming - The machine will not start up even if the main
power is turned ON.
Service call error C0060 appears.
to the ErP New Old New X
(Improper control PWB is installed.)
Lot6 - Service call error C6400 (zero cross signal error)
appears when machine enters the sleep mode.
New New Old X
- The machine will not start up even if the main
power is turned ON.
Service call error C0060 appears.
New New New X
(Improper control PWB is installed.)
The machine will not start up even if the main power
Old Old Old X
is turned ON.
Service call error C6400 (zero cross signal error)
Old Old New X
appears due to improper switching regulator.
The machine will not start up even if the main power
Old New Old X
is turned ON.
Service call error C6400 (zero cross signal error)
Old New New X
appears due to improper switching regulator.
New control PWB (No.12)
Engine
Switching Main
Main Unit Firmware Operation Remarks
Regulator Firmware
(Note 2)
Current Old Old New Old operation
model Old New New Old operation
New Old New Old operation
New New New Old operation
New model New New New Lot6 Correct combination
conforming New Old New Old operation
Service call error C6400 (zero cross signal error)
to the ErP Old New New X
appears due to improper switching regulator.
Lot6 Service call error C6400 (zero cross signal error)
Old Old New X
appears due to improper switching regulator.
(Note2) The engine firmware of the old version cannot be downloaded onto the new control PWB and the download error may
be displayed.
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
(Page.4/5)
Service Bulletin Ref. No. 2LY-0005 (C284)
October 23, 2012
[Firmware Upgrade]
No. Item Details CTL FW
1 Conformity to the ErP Lot6 The main power OFF timer function is now supported. 621026 MAIN
Change of the initial setting for
The initial setting for European area was changed from 15
2 Energy Star Timer (FRPO N5) 628467 MAIN
min. to 5 min.
for European area
3 Conformity to the ErP Lot6 The Config Tool was changed. CD
4 Conformity to the ErP Lot6 The Operation Guide was revised. CD
Check Current
Type Program No. Ver. Status Date Remark
SUM Ver.
MAIN 2LZ_3000005005 - 005.005 2012/6/21 004.001 <-- New upgrade
ENGINE 2LY_1000005002 be8e 005.002 - 003.001 FS-1120D <-- New upgrade
ENGINE 2LZ_1000005002 8144 005.002 - 004.001 FS-1320D <-- New upgrade
Kyocera Product Library (for KDE) 1.2 1.1 For KDE <-- New upgrade
Product Library 1.2 1.1 For Olivetti <-- New upgrade
Product Library 1.2 1.1 For UTAX/TA <-- New upgrade
For the KD sales companies, it is possible to download the firmware at the download center on the Service World.
When upgrading the firmware or replacing a board, please upgrade all kinds of the firmware (MAIN, ENGINE) to the latest
version at the same time.
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
(Page.5/5)
Service Bulletin Ref. No. 2LY-0005 (C284)
October 23, 2012
Com pati-
Old Part New Part Q'ty bi lity
No. No. No. Description Remarks
Old New Old New
302LZ04010 302LZ04011 X
1 COVER LEFT 1 1 O
2LZ04010 2LZ04011 (*1)
302LZ04090
2 ------------ COVER MAIN SW - 1 - X *2
2LZ04090
302HS46120 302LZ46030
3 CONN.CORD.ASSY S03808 1 1 X X *2, *3
2HS46120 2LZ46030
302HS45013 302LZ94170 PARTS SWITCHING REGULATOR
4 1 1 X X *2
2HS45013 2LZ94170 230V SP
302LY04010 302LY04020 *4
5 COVER RIGHT 2 1 1 X X
2LY04010 2LY04020 FS-1120D (*2)
302LZ04020 302LZ04080 *4
5 COVER RIGHT 2 1 1 X X
2LZ04020 2LZ04080 FS-1320D (*2)
302LZ04070
6 ------------ HOLDER KEY SW - 1 - X *2
2LZ04070
302F931270
7 ------------ SPRING FUSER - 1 - X *2
2F931270
302LZ04060
8 ------------ KEY POWER - 1 - X *2
2LZ04060
302LZ04050
9 ------------ MOUNT PWB SW - 1 - X *2
2LZ04050
7BB700308H
10 ------------ (+) BIND T.T S SCREW 3X8 SR - 1 - X *2
BB105600
302LZ94180
11 ------------ PARTS PWB ASSY SWITCH SP - 1 - X *2
2LZ94180
302LY94010 302LY94040 X
12 PARTS PWB CONTROL SP 1 1 O FS-1120D
2LY94010 2LY94040 (*1)
302LZ94080 302LZ94160 X
12 PARTS PWB CONTROL SP 1 1 O FS-1320D
2LZ94080 2LZ94160 (*1)
(Caution) Please use the parts conforming to the ErP Lot6 for the models conforming to the ErP Lot6.
As for the current models, please use the old parts except No.1 and No.12. Both of the new and the old parts of No.1 and
No.12 can be used.
*1: Please make sure to use the new parts for the models conforming to the ErP Lot6. Either of the new or the old parts
can be used for the current models.
*2: The change was applied only for the models conforming to the ErP Lot6.
*3: (Old part name) CONN.CORD.ASSY PWD-INLET S03238
*4: (Old part name) COVER RIGHT
Serial Nos. of the Affected Machines
st rd
Product Code for 1 to 3
New Product Serial Number
Model Name Destination st rd the Current Digits of the
Code (1 to 3 digits are unique)
Models Serial Number
FS-1120D 1102LY3NL2 KDE L4W2600001 1102LY3NL0 NP3
1102LY3UT1 UTAX/TA L5C2800001 1102LY3UT0 Q7Q
1102LY3LV1 Olivetti L5Y2900001 1102LY3LV0 Q9T
FS-1320D 1102LZ3NL2 KDE L4X2600001 1102LZ3NL0 Q63
1102LZ3UT1 UTAX/TA L5D2900001 1102LZ3UT0 Q7R
1102LZ3LV1 Olivetti L5Z2900001 1102LZ3LV0 Q9U
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
