Service Bulletin Ref. No. 2LZ-0006 (B443)
December 17, 2011
Improvement of the Preventive Margin for the Paper Detection
Subject
Actuator
FS-1100, FS-1300D, FS-1350DN, FS-1120D, FS-1320D,
FS-1370DN, FS-1110, FS-1028MFP, FS-1128MFP,
Model
FS-1024MFP, FS-1124MFP, FS-1030MFP, FS-1130MFP,
FS-1035MFP, FS-1135MFP
Topic
If the cassette is fully filled with paper, the leading edge of the actuator might be caught up by the paper and paper
empty might be erroneously detected. Therefore, the angle of the actuator stoppage was changed in order to
improve the margin.
Due to the change above, the shape of the PLATE COVER DU was changed in order to prevent interference by the
COVER DU.
Content of Changes
1 Shape change of the ACTUATOR EMPTY A
(Change of the actuator stoppage angle) 0.8 mm
After
Paper feeding
direction
After
10o lowered Before
Paper
2 Change of the PLATE COVER DU
New Actuator
Old
Actuator interfered
by the cover
COVER DU
Cut out portion
Com pati-
Old Part New Part Q'ty bi lity
No. No. No. Description Remarks
Old New Old New
302LZ06010 302LZ06011
1 ACTUATOR EMPTY A 1 1 O X
2LZ06010 2LZ06011
302HS94330 302HS94331 PARTS PLATE COVER DU
2 1 1 X O
2HS94330 2HS94331 ASSY SP
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.2/2)
Service Bulletin Ref. No. 2LZ-0006 (B443)
December 17, 2011
KMC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure:
Please use the new type of the COVER DU (No.2) when replacing the actuator with the new type of the
actuator (No.1) since the old COVER DU interferes with the new actuator.
Serial Nos. of the Affected Machines: Planned from the November 2011* production
*The above is the plan at the present moment. Please note that this information is subject to change.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
