(Revised Issue 1) (Page.1/2)
Service Bulletin Ref. No. COM-0212 (B007)
July 29, 2011
Notes on Replacement of the Part (Change of the BUSH
Subject
REGIST C)
FS-1100, FS-1300D, FS-1350DN, FS-1120D, FS-1320D,
Model
FS-1370DN, FS-1028MFP, FS-1128MFP
This time, the description with (-->) was revised from the previous information.
(New) Tenac-C LZ750 (Both POM resin)
Color : (Old) White --> (New) Black
Frame
[BUSH REGIST C (No1)]
(Old) (New)
Material: TYSTRON 4510 Material: Tenac-C LZ750
Com pati-
Old Part New Part Q'ty bi lity
No. No. No. Description Remarks
Old New Old New
2FM02180 302LZ24220
1 BUSH REGIST C 1 1 X O
5MVX221DN020 2LZ24220
KMC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: Please use the new BUSH REGIST C (black) when replacing the part.
Serial Nos. of Affected Machine: (-->) Please refer to the next page.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Revised Issue 1) (Page.2/2)
Service Bulletin Ref. No. COM-0212 (B007)
July 29, 2011
Model Destination Serial Number Destination Serial number
KME From QQX0909698 KMA From QRB0800931
KTST From Q2M0X00642 KMKR From Q3C0Z00115
FS-1028MFP Olivetti From QUX0901296 KMSG From QVE0X00001
UTAX From QVB0903071 TA From Q110903438
KMHK From next production KMTH From next production
KME From QUV0822948 KMA From QVD0904402
KMAUS From QVM0900210 KTST From Q2N0X00347
FS-1028MFP/DP KMSG From QVF1200001 KMTH From QYV0900455
Olivetti From QVN0901712 KMHK From next production
KME (KMIS) From NPW1500001
KMA (120V) From XVN0917124 KMA (240V) From XYN0803468
KM-2810
ADVANSYS From QXV0901835
KME From QRD0836727 KMA From QRH0919745
KMSP From QUW0905013 KMAUS From QRE0X02269
KMSG From QVG0X00483 KMTH From QRG0X00692
FS-1128MFP
KMKR From Q3D0900525 KTST From Q2L0X00388
KMID From N8Z0Z00001 Olivetti From QUY0905444
UTAX From QVC0910411 TA From Q120905276
KMA (120V) From XVP0908671 KMA (240V) From XYP0X01051
KM-2820
ADVANSYS From QXW0X00845
KME From Q5Y0617310 KMA From Q5X0X08721
KMA (240V) From Q5U0700414 KMSG From Q910700004
KMTW From Q9P0800001 KMAUS From Q5Z0701575
FS-1120D
KMTH From Q920700061 KMKR From Q9L0700441
UTAX From Q7Q0700001 Olivetti From Q9T0700271
KME (CONSIP) From NP31300001
KME From Q630717328 KMA (240V) From Q5V0700312
KMA From Q620705501 KTST From N7K0Z00001
KMSG From Q930700104 KMAUS From Q640701112
FS-1320D
KMTW From Q9Q0800001 KMKR From Q9M0700645
KMTH From Q940700041 KMID From N910Z00001
Olivetti From Q9U0700261 UTAX From Q7R0701591
KMA From Q650703491 KMA (240V) From Q5W0700091
KME From Q660708641 KMAUS From Q670700826
KMTH From Q950800101 KMTH From NM51200001
FS-1370DN
KMKR From Q9N0700081 KMTW From N1M0700001
KMSG From N1E0X00004 UTAX From Q7S0702431
KMJ From Q7N1402352
Other models: From next production
