Image preview - the first page of the document
>> Download 2L0-004 documenatation <<
Text preview - extract from the document
Service Bulletin
SB Number: SB 2L0-004 Creation Date: 29/11/2011
Subject: Firmware upgrade (System v004.006)
Model: FS-1370DN
Item Contents
1 Improper Prescribe If the character codes 0x21, 0x52 and 0x21 (!R!) are included in PCL5 data, Prescribe
entry. mode may unintentionally be entered and no data may be printed afterwards.
2 Garbled characters. Characters on the 2nd page may appear garbled, when scanning to FTP.
3 Improper font height. The font height may appear incorrect, when printing Intellifont with different resolution
for the X and Y direction.
Firmware
Type Program No. Check SUM Version Status Date
SYSTEM 2L0_3000003001 98ac 004.006 09/09/2011
ENGINE 2L0_1000002003 1ded 002.003 22/06/2011
Classification Entire stock rework X In-field modification by case No modification necessary
In-field modification at next visit
Field measure When the above mentioned phenomena occur, please upgrade the firmware to the latest
version.
KMIS Service Department, Kyocera Mita Europe Page of B377 / SB 2L0-004
