Image preview - the first page of the document
>> Download 2LZ-001 documenatation <<
Text preview - extract from the document
Service Bulletin SB Number: SB 2LZ-001 Creation Date: 25/08/2010 Subject: Firmware upgrade (The transfer ON timing has been changed) Model: FS-1120D/1320D The transfer ON timing of the second side leading edge has been adjusted to improve the duplex printing. Firmware Type Program No. Check SUM Version Applicable models Status Date SYSTEM 2LZ_3000002001 9497 002.001 FS-1120D/1320D 10/02/2010 ENGINE 2LY_1000002001 8a73 002.001 FS-1120D 29/03/2010 ENGINE 2LZ_100002001 576b 002.001 FS-1320D 29/03/2010 Classification Entire stock rework In-field modification at next visit In-field modification by case No modification necessary Field measure Please upgrade the firmware to the latest version to implement the above mentioned changes. Serial numbers of affected machines Type Serial number FS-1120D/1320D April 2010 production. The above mentioned changes have been applied to machines produced after the above mentioned production date. KMIS Service Department, Kyocera Mita Europe Page 1 of 1 A138 / SB 2LZ-001
