Image preview - the first page of the document



>> Download 2J0-005 documenatation <<

Text preview - extract from the document

                                    Service Bulletin
 SB Number: SB 2J0-005                                                       Creation Date: 26/02/2010
 Subject:             Firmware upgrade
 Model:               FS-2020D/3920DN/4020DN


Content of changes
    Item                    Contents
1   Direct printing         Direct printing of XPS data has been added.
2   Print pattern           The default resolution for direct printing has been added for TIFF and JPEG files.
3   Pop up function         The print menu will automatically appear on the operation panel, when an USB drive is
                            inserted in the USB host.
4   XPS printing from       The machine can print out XPS data received through E-mail from Kyocera MFP models.
    E-mail
6   MP tray                 Phenomenon
                            When the default cassette is set to MP tray the following may occur:

                            1. The indication of paper empty for the MP tray is switched OFF.
                            2. The "Add paper warning" is indicated, when the standard paper cassette and
                               multi purpose tray are empty.

                            Solution
                            Please use one of the following methods:

                            1. Operation panel:
                               Device Common        Error Handling     Set the MP Tray Empty setting to "OFF"
                            2. Command center:
                               Basic      Device Defaults     Set the MP Tray Empty setting to "OFF"
                            3. Prescribe command:
                               !R!MPTE 0;EXIT;(MPTE 1;On)
7   Several e-MPS           The following e-MPS functions have been added:
    functions have been
    added.                  Custom Box, Quick Copy, Print Job Stay, Proof print and Private print.
                            Please see the table below for further details.




Added e-MPS functions
    Items                 Details                    Necessary machine modification
1   Custom Box            It is possible to select     Install a hard disk in the machine.
    Quick Copy            specified file or all print.
    Print Job stay
2   Proof print           It is possible to select     Allocate a part of the machines internal memory as a Ram disk or
    Private Print         specified file or all print. install a hard disk in the machine.




Firmware
Type                                      Program No.                   Check SUM Version          Status Date
SYSTEM                                    2J0_3000.005.017              69b0           005.017     29/07/2009



KMIS Service Department, Kyocera Mita Europe                  Page  of 2                               8988 / SB 2J0-005
                                      Service Bulletin

Classification      Entire stock rework    In-field modification at next visit   In-field modification by case   No modification necessary
Field measure     To implement the above mentioned changes, please upgrade the firmware to the latest version.
                  Ensure that the engine firmware is version 2J0_1000.002.008 or later.



Serial numbers of affected machines
Type                                                              Serial number
FS-2020D                                                          XEX9827983
FS-3920DN                                                         Not available
FS-4020DN                                                         XEZ9806805
Machines produced after the above mentioned serial numbers, are affected by the above mentioned changes.




KMIS Service Department, Kyocera Mita Europe                      Page 2 of 2                                          8988 / SB 2J0-005
