Image preview - the first page of the document



>> Download 2J0-010 documenatation <<

Text preview - extract from the document

                                      Service Bulletin
 SB Number: SB 2J0-010                                                               Creation Date: 30/09/2010
 Subject:            Firmware upgrade
 Model:              FS-2020D/3920DN/4020DN


    Item                                  Contents
1   Paper jams.                           Paper jams may occur, when printing on mixed sized paper.
2   Continous motor drive.                The main motor may drive continuously, when the drum refresh is activated
                                          when the toner is low in case the main switch is turned ON or when closing
                                          one of the covers.


Firmware
Type          Program No.           Check SUM              Version                   Status Date        Applicable Model
SYSTEM        2J0_3000006002 fcaf                          006.002                   24/02/2010         FS-2020D/3920DN/4020DN
ENGINE        2J0_1000004002 36DE                          004.002                   -                  FS-2020D
ENGINE        2J1_1000004002 5602                          004.002                   -                  FS-3920DN
ENGINE        2J2_1000004002 BF83                          004.002                   -                  FS-4020DN



Classification      Entire stock rework      In-field modification at next visit   In-field modification by case   No modification necessary
Field measure     When the above mentioned phenomenon occurs, please upgrade the firmware to the latest
                  version.


Serial numbers of affected machines
Type                                                                Serial number
FS-2020D/3920DN                                                     Not available
FS-4020DN                                              XEZ0927798
Machines produced after the above mentioned serial numbers, should not have the above mentioned phenomena.




KMIS Service Department, Kyocera Mita Europe                        Page 1 of 1                                         A305 / SB 2J0-010
