Image preview - the first page of the document
>> Download SB-2LV-0004-C309 documenatation <<
Text preview - extract from the document
(Page.1/3)
Service Bulletin Ref. No. 2LV-0004 (C309)
December 4, 2012
Subject Firmware Upgrade (Engine firmware ver.002.003 003.001)
FS-2100D(N)_FS-4x00DN_v.06.00.0020_(2012-11-16)
Model FS-2100D, FS-2100DN, FS-4100DN, FS-4200DN, FS-4300DN l:
KDC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure:
Please upgrade the firmware to the latest version when the phenomenon described below occurs.
Serial Nos. of the Affected Machines: Please refer to the following pages.
Topic
The firmware was upgraded as follows.
Content of Changes
No. Item Details CTL FW Ver.
1 Measures against the Fusing failure may occur on the 40 ppm model in low temperature 654830 ENGINE 002.003
fusing failure with small environment when printing A5 size paper.
size paper Therefore, this was corrected.
2 Change of the Paper jam may occur at the switchback section when printing in 66059 ENGINE 002.003
switchback timing in duplex mode. Therefore, this was corrected.
duplex mode
3 Measures for the fusing Fusing failure may occur on the 60/50/45 ppm models when all of 794682 ENGINE 003.001
failure in duplex mode the following conditions are met. Therefore, this was corrected.
- Normal speed printing
- Intermittent printing
- Duplex printing
- Paper weight is set to Normal or Light.
Check Status Current
Type Program No. Ver. Remark
SUM Date Ver.
MAIN 2L2_3F00004008 - 004.008 2012/10/19 - FS-2100D
MAIN 2LV_3F00004008 - 004.008 2012/10/19 - *1
ENGINE 2LV_1000003001 - 003.001 - - New Upgrade
Language 2LV_81BR001008 - 001.008 - - Brazilian Portuguese
Language 2LV_81TW001001 - 001.001 - - Traditional Chinese
For the KD sales companies, it is possible to download the download center on the Service World.
When upgrading the firmware or replacing a board, please upgrade all kind of the firmware to the latest version at the same
time.
*1: FS-2100DN, FS-4100DN, FS-4200DN, FS-4300DN
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
(Page.2/3)
Service Bulletin Ref. No. 2LV-0004 (C309)
December 4, 2012
Serial Nos. of the Affected Machines
ENGINE 2LV_1000.002.003 2LV_1000.003.001
Item Code Serial Number Serial Number
FS-2100D KDA 1102L22US0 N/A Next production
KDE 1102L23NL0 From NUA2X02615 From NUA2Y03211
KDAU 1102L23AS0 From NU92X00334 From NU92Y00437
UTAX/TA 1102L23UT0 From NY92X00069 From NY92Y00093
KDSG/KDHK 1102L23SG0 N/A From L5J2X00140
KDID 1102L23ND0 N/A Next production
KDTH/Philcopy 1102L23TH0 From L5K2X00006 From L5K2Y00020
KDKR 1102L23KR0 N/A Next production (Plan: Dec. 6, 2012)
FS-2100DN KDA 1102MS2US0 From NUF2X02232 From NUF2X02764
KDE 1102MS3NL0 From NUH2X09787 From NUH2Y11497
KDAU 1102MS3AS0 From NUG2X00460 From NUG2Y00609
UTAX/TA 1102MS3UT0 From NYB2X01353 From NYB2Y01973
KDA (GSA) 1102MS2US1 N/A Next production
KDA (South America) 1102MS4US0 From L3X2X00039 From L3X2Y00061
KDSG/KDHK 1102MS3SG0 From L5M2X00017 From L5M2Y00039
KDID 1102MS3ND0 N/A Next production
KDTH/Philcopy 1102MS3TH0 From L5N2X00006 From L5N2Y00020
KDTW 1102MSTTW0 N/A Next production (Plan: Jan. 11, 2013)
KDCN 1102MS3KS0 N/A Next production (Plan: Dec. 6, 2012)
KDKR 1102MS3KR0 N/A Next production (Plan: Dec. 6, 2012)
Olivetti 1102MS3LV0 N/A From L932Y00073
FS-4100DN KDA 1102MT2US0 N/A From NUK2X03427
KDE 1102MT3NL0 From NUM2X06658 From NUM2X07542
KDAU 1102MT3AS0 N/A From NUL2Y00286
UTAX/TA 1102MT3UT0 From NYC2X00372 From NYC2Y00462
KDA (South America) 1102MT4US0 N/A Next production
KDSG/KDHK 1102MT3SG0 N/A From L5Q2Y00012
KDID 1102MT3ND0 N/A Next production
KDTH/Philcopy 1102MT3TH0 N/A From L5R2Y00006
KDTW 1102MTTTW0 N/A Next production (Plan: Dec. 28, 2012)
KDCN 1102MT3KS0 N/A Next production
KDKR 1102MT3KR0 N/A Next production (Plan: Dec. 21, 2012)
Olivetti 1102MT3LV0 From L942X00151 From L942Y00271
FS-4200DN KDA 1102L12US0 From NU42X04012 From NU42X04295
KDE 1102L13NL0 From NU62X08742 From NU62X11786
KDAU 1102L13AS0 N/A From NU52X00111
UTAX/TA 1102L13UT0 From NY82X01348 From NY82Y02029
KDA (GSA) 1102L12US1 N/A Next production
KDA (South America) 1102L14US0 N/A From L3Z2X00001
KDSG/KDHK 1102L13SG0 N/A From L5T2Y00001
KDID 1102L13ND0 N/A Next production
KDTH/Philcopy 1102L13TH0 N/A From L5U2Y00005
KDTW 1102L1TTW0 N/A Next production
KDCN 1102L13KS0 N/A Next production
KDKR 1102L13KR0 N/A Next production (Plan: Dec.19, 2012)
Olivetti 1102L13LV0 From L952X00081 From L952Y00141
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
(Page.3/3)
Service Bulletin Ref. No. 2LV-0004 (C309)
December 4, 2012
ENGINE 2LV_1000.002.003 2LV_1000.003.001
FS-4300DN KDA 1102LV2US0 NUB2X00522~ NUB2Y00788~
KDE 1102LV3NL0 NUD2X04567~ NUD2Y04790~
KDAU 1102LV3AS0 NUC2X00048~ NUC2Y00064~
UTAX/TA 1102LV3UT0 N/A NYA2Y00080~
KDA (South America) 1102LV4US0 N/A Next production
KDSG/KDHK 1102LV3SG0 N/A L5W2Y00009~
KDID 1102LV3ND0 N/A Next production
KDTH/Philcopy 1102LV3TH0 L5X2X00005~ L5X2Y00014~
KDTW 1102LVTTW0 N/A Next production
KDCN 1102LV3KS0 N/A Next production (Plan: Dec. 20, 2012)
KDKR 1102LV3KR0 N/A Next production (Plan: Dec. 20, 2012)
KDE 1102LV3NL1 L4U2X01602~ L4U2Y01673~
