Image preview - the first page of the document
>> Download SB-2LV-0009-D031 documenatation <<
Text preview - extract from the document
(Page.1/2)
Service Bulletin Ref. No. 2LV-0009 (D031)
February 26, 2013
Firmware Upgrade (Main: Ver.007.006; Engine: Ver.004.003;
Subject Optional Languages)
FS-2100D(N)_FS-4x00DN_v.07.00.0010_(2013-01-15)
Model FS-2100D, FS-2100DN, FS-4100DN, FS-4200DN, FS-4300DN l:
KDC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: Please upgrade the firmware to the latest version when the phenomenon described
below occurs.
Serial Nos. of the Affected Machines: To be informed later
Topic
The firmware was upgraded as follows.
Content of Changes
No. Item Details CTL FW
1 Change of the message "Internal memory" was changed to "SSD". 671944 MAIN
799440 LANGUAGE
2 Display of the affected The affected cassette is now displayed when Paper Path Error 672392 MAIN
799440 LANGUAGE
cassette when Paper occurs.
Path Error occurs Ex.) Paper path error. Set Cassette 1.
3 Support of the DUPX It is now enabled to execute the DUPX command during the 730504 MAIN
command during the auto macro.
auto macro
4 Measures against the The system error F000 or F245 might appear when turning the 658704 MAIN
system errors main power ON. Therefore, this was corrected.
(F000, F245)
5 (For Olivetti) UG-33 (ThinPrint) is now supported when set to Olivetti. 799138 MAIN
Support of UG-33
(ThinPrint)
6 Measures against the The barcode defined character pitches were broadened when 672684 MAIN
TP-11-010
barcode scanning error the size was reduced from SF to A4. Therefore, this was NP-Z11002
corrected.
7 Improvement of the PDF The output time for a certain PDF data was reduced. 730131 MAIN
TP-11-245
data output performance #1356440
8 Performance The PCL data output from the user system (Print2000) was not 730141 MAIN
TP-12-082
improvement of the data performed at expected speed. Therefore, this was corrected. ESha12032
output from the user 8-1
system
9 Measures against the The machine might be locked when outputting from Mac Vector 730915 MAIN
TP-12-160
machine lockup when Works. Therefore, this was corrected. NP-Z12041
using a certain
application
10 Support for KDTW The control was changed to support KDTW. 802640 ENGINE
(The control for other than KDTW remains unchanged.
This will be implemented from the first production for KDTW.)
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
(Page.2/2)
Service Bulletin Ref. No. 2LV-0009 (D031)
February 26, 2013
Check Status Current
Type Program No. Ver. Remark
SUM Date Ver.
MAIN 2L2_3F00007006 - 007.006 2013/1/15 006.003 FS-2100D New upgrade
MAIN 2LV_3F00007006 - 007.006 2013/1/15 006.003 *1 New upgrade
MAIN 2LV_3F00C06006 - C06.006 2013/1/8 - *1 (For KDTW) New set
ENGINE 2LV_1000004003 - 004.003 - 003.003 New upgrade
Optional Brazilian
2LV_81BR001010 - 001.010 - 001.009 New upgrade
language Portuguese
Optional
2LV_81CN001003 - 001.003 - 001.002 Simplified Chinese New upgrade
language
Optional
2LV_81KR001002 - 001.002 - - Korean New set
language
Optional Traditional
2LV_81TWC01004 - C01.004 - - New set
language Chinese
*1: FS-2100DN, FS-4100DN, FS-4200DN, FS-4300DN
For the KD sales companies, it is possible to download the firmware at the download center on the Service World.
When upgrading the firmware or replacing a board, please upgrade all kinds of the firmware to the latest version at the same
time.
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
