Image preview - the first page of the document
>> Download SB-3KF-0003-C313 documenatation <<
Text preview - extract from the document
(Page.1/2)
Service Bulletin Ref. No. 3KF-0003 (C313)
December 4, 2012
Subject Discharger Brushes Added to the TABLE PAPER
Model PF-315, PF-315+ l:
(Affected models)
PF-315: FS-3900DN, FS-4000DN, FS-3920DN, FS-4020DN
PF-315+: FS-2100D, FS-2100DN, FS-4100DN, FS-4200DN, FS-4300DN
KDC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measures:
When the phenomenon described below occurs, please first replace the PF main PWB (303KF01020) with the
new one and then affix the DISCHRAGER TP (No.1) to the indicated positions on rear side of the TABLE
PAPER. (After cleaning the affixing part with alcohol, please affix No.1 according to the alignments.)
Serial Nos. of the Affected Machines: Please refer to the next page.
Topic
In a very rare case, static electricity on the TABLE PAPER was short-circuited to the side plate attached the PF
main PWB after paper feeding which cause damage to the motor driver IC on the PF main PWB (303KF01020)(*).
Therefore, the discharger brushes (DISCHARGER TP: No1) were added to the rear side of the TABLE PAPER to
secure the antistatic function.
* If the motor driver IC is damaged, the TABLE PAPER cannot be lifted up, which causes no paper feed jam.
1. Two pcs. of the DISCHARGER TP (No.1) were added to the TABLE PAPER.
(PF main Positions of the discharger brushes
PWB side)
TABLE PAPER
Brush shall not Rear side of the TABLE PAPER
stick out from the
metal plate width.
Leading edge of
the brush base
Alignment to
the edge of the
metal plate
Allowable range of stick-out: +2/-0 mm
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
(Page.2/2)
Service Bulletin Ref. No. 3KF-0003 (C313)
December 4, 2012
Com pati-
Old Part New Part Q'ty bi lity
No. No. No. Description Remarks
Old New Old New
303KF04120
1 ----- DISCHARGER TP - 2 - O
3KF04120
Serial Nos. of the Affected Machines
Model Destination Item No. Serial Number
PF-315 Other than KDCN 1203KF0KL0 Next production
KDCN 1203KF8KS0 Next production
PF-315+ Other than UTAX and Olivetti 1203KF0KL1 L4Y2Z00336 (Plan)
UTAX 1203KF8UT0 Next production
Olivetti 1203KF8LV0 L972Z00019 (Plan)
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
