Item Content FW 1 Change of the Print The description on the service status page was changed from "Digital Dot Coverage" MAIN Coverage description on to "Print Coverage". status page - The coverage is simply converted with the area image ratio based on the current dot number data, and the accuracy as reference value of the toner consumption was improved. - When upgrading the firmware, the Digital Dot Coverage data will be reset due to the different way of calculation. 2 Support of ID Card ---------------------------------------- MAIN Reader (Elatec type) LAN 3 Support for language This was changed so that language selection menu can be displayed to select MAIN selection at startup language when the machine is started up for the first time. (For KMA, Central/South When turning the power ON next time, the language selected first will be set. America, KME, UTAX, After language selection: Olivetti only) - Language is set by pressing "OK" key and language selection menu will not be displayed when turning the power ON next time. --> The Quick - If pressing "Clear" key, language is set to English which is default setting, and Installation Guide for the language selection menu will be displayed when turning the power ON next time. affected destinations - If pressing "Cancel" button on the LCD, language is set to English which is was changed due to the default setting, and language selection menu will not be displayed when turning change above. the power ON next time. ENG 4 Support for KMTW ---------------------------------------- MAIN LAN 5 Measure against CF248 CF248 might appear when printing certain file at user site. Therefore, this was MAIN with certain file corrected. 6 New network The server type was added to the network authentication setting. MAIN authentication setting --> Accordingly, a leaflet was added. 7 Support for KMTW The Operation Guide for KMTW was added. CD Check Status Current Program No. SUM Ver. Date Ver. Remark ENGINE 2LW_1000.003.003 - 003.003 2010/10/28 - <-- New upgrade <-- New upgrade MAIN 2LW_2F00.005.012 - 005.012 - 004.003 (FS-3040MFP) <-- New upgrade MAIN 2LX_2F00.005.012 - 005.012 - 004.003 (FS-3140MFP) KYOCERA MITA Europe B.V. European Service & Development Center (ESDC) (Revised Issue 1) (Page.2/3) Service Bulletin Ref. No. 2LW-0007 (A365) May 31, 2011 Optional language KR 2LW_81KR.001.014 - 001.014 - 001.008 <-- New upgrade (For KMKR) Optional language TW 2LW_81TW.001.009 001.009 - - <-- New setting (For KMTW) <-- New upgrade Optional language BR 2LW_81BR.001.015 - 001.015 - 001.010 (Brazilian Portuguese) FAX BOOT/APL 2H9_5500003003 - 003.003 - - MIX F/W of BOOT and APL For the KM sales companies, it is possible to download firmware at the download center on the ESDC.net. When upgrading the firmware or replacing a board, please upgrade each kind of the firmware to the latest version at the same time. KMC's Classification Entire Stock Rework In-Field modification at next visit In-Field modification by case No modification necessary Field Measure: No particular problem is expected. However, please use the correct optional language firmware since characters may be garbled. Serial Nos. of the Affected Machines: (The CD-ROM upgrade will be implemented after using up the old stock.) MODEL Destination Destination KMA (220) From Q8E0Y01931 KMTH From N1L0Y00026 KMAUS From Q8G0Y00111 KMSG From N1K0Y00001 ( ) FS-3040MFP KMTW From N6Y0Y0001 Serial Nos. of the Affected Olivetti From N6K0Y00296 UTAX From Q8H0Y00625 Machines KME From Q8L0Y04219 From N1H0Y00005 KMSG KMA From Q8K0Y05847 KMTW From N6Z0Y00001 FS-3140MFP KMAUS From Q8M0Y00730 KMTH From N1J0Y00026 Olivetti From N6J0Y00421 UTAX From Q8N0Y00931 KYOCERA MITA Europe B.V. European Service & Development Center (ESDC) (Revised Issue 1) (Page.3/3) Service Bulletin Ref. No. 2LW-0007 (A365) May 31, 2011 Added content: Language selection screen comes to be displayed when turning on the power for the applicable destination*. Therefore, the following illustration is added to Quick Installation Guide as the procedure after the main switch is turned on. * KMA, Central/South America (KMA), KME, UTAX and Olivetti The illustration above was added to the Quick Installation Guide for all destinations other than KMJ, KMTW, KMTW, KTST and KMKR. Please note that the language selection screen above will not be displayed on the units for Asia and Australia. A correction leaflet is now inserted since "Ext." was added as a server type in network authentication. (Please refer to the attached file for the languages other than English.) KYOCERA MITA Europe B.V. European Service & Development Center (ESDC)
