Image preview - the first page of the document
>> Download SB-2LW-0011-B382 documenatation <<
Text preview - extract from the document
(Page.1/2)
Service Bulletin Ref. No. 2LW-0011 (B382)
November 10, 2011
Firmware Upgrade (FAX: Ver.007.002 (Except KTST);
Subject Scanner: Ver.002.001; Optional Language: Ver.001.015 (KMKR),
Ver.001.013( KMTW))
FS-3040MFP_FS-3140MFP_v.08.00.0030_(2011-02-07)
Model FS-3040MFP, FS-3140MFP
Topic
The firmware was upgraded as follows.
Content of Changes
No. Item Details CTL No. FW
556269 FAX
1 Support for Mexico The Mexican country code was added.
488853 SCA
2 Measure against the copy If DP was closed during scanning the original and copy was TC-10-034
image dropout started in the state of opening DP after putting the original on the
(Only leading edge or trailing contact glass, only the image at the time of closing DP might be
edge of the image was printed, or only the trailing edge of the original might be printed
printed.) depending on the timing of closing DP. Therefore, this was
corrected.
(No particular problem is expected if copy is executed by using
DP.)
538810 SCA
3 Measures against the solenoid The DP reverse solenoid might not be released after completing
motion failure the duplex scanning. Therefore, this was corrected.
4 LAN
Support for KMKR and KMTW Change was made in order to support the FS-3140MFP+.
Program No. Check Ver. Status Date Current Remark
SUM Ver,
ENGINE 2LW_1000004001 6EAA 004.001 2011/6/10 003.003
MAIN 2LW_2F00008003 008.003 - 007.010 FS-3040MFP
MAIN 2LX_2F00008003 008.003 - 007.010 FS-3140MFP
SCANER 2LW_1200002001 002.001 2011/6/10 001.013 New upgrade
Optional language 2LW_81KR00101 001.015 - 001.014 For KMKR New upgrade
KR 5
Optional language 2LW_81TW00101 001.013 - 001.009 For KMTW New upgrade
TW 3
Optional language 2LW_81BR00101 001.015 - - For KMBR
BR 5
Optional language 2LW_81CN00101 001.012 - 001.010 For KTST
CN 2
FAX BOOT/APL 2H9_5500007002 007.002 - 006.001 Except KTST New upgrade
FAX BOOT/APL 2H9_5700N05001 N05.001 - N04.002 For KTST
For the KM sales companies, it is possible to download the firmware at the download center on the ESDC.net.
When upgrading the firmware or replacing a board, please upgrade all kinds of the firmware to the latest version at the same
time.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.2/2)
Service Bulletin Ref. No. 2LW-0011 (B382)
November 10, 2011
KMC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: Please upgrade the firmware when the problem described above arises.
Serial Nos. of the Affected Machines: Planned from the October 2011* production
*The above is the plan at the present moment. Please note that this information is subject to change.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
