Image preview - the first page of the document
>> Download SB-2LX-0005-B161 documenatation <<
Text preview - extract from the document
(Page.1/1)
Service Bulletin Ref. No. 2LX-0005 (B161)
June 21, 2011
Firmware Upgrade
Subject (FAX: Ver.006.001 except KTST specifications)
FS-3040MFP_FS-3140MFP_v.08.00.0020_(2011-02-07)
FS-3040MFP+_FS-3140MFP+_v.1.00.0030_(2011-04-14)
Model FS-3140MFP
Topic
The firmware was upgraded as follows.
Content of changes
No. Item Details CTL FW
1 Support for Russia Russian country code was added. 520572 FAX
541200
2 538261 FAX
Support of FS-3140MFP+ --------
Type Program No. Ver. Status Current Ver. Remark
Date
ENGINE 2LW_1000.003.003 003.003 2010/10/28 -
MAIN 2LW_2F00. 008.003 008.003 - 007.010 FS-3040MFP
MAIN 2LX_2F00. 008.003 008.003 - 007.010 FS-3140MFP
SCANER 2LW_1200.001.013 001.013 - -
Optional language KR 2LW_81KR.001.014 001.014 - For KMKR
Optional language TW 2LW_81TW.001.009 001.009 - - For KMTW
Optional language BR 2LW_81BR.001.015 001.015 - - For KMBR
Optional language CN 2LW_81CN.001.012 001.012 - 001.010 For KTST
FAX BOOT/APL 2H9_5500.006.001 006.001 - 003.003 Except KTST <-- New
upgrade
FAX BOOT/APL 2H9_5700.N05.001 N05.001 - N04.002 For KTST
For the KM sales companies, it is possible to download the firmware at the download center on the ESDC.net.
When upgrading the firmware or replacing a board, please upgrade each kind of the firmware to the latest version at the same
time.
KMC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: Please upgrade the firmware if necessary.
Serial Nos. of the Affected Machines: After using up the old stock of the FAX board
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
