Image preview - the first page of the document



>> Download SB-2LX-0006-B203 documenatation <<

Text preview - extract from the document

                                                                                                                          (Page.1/1)

           Service Bulletin                                                             Ref. No.   2LX-0006 (B203)
                                                                                                    July 11, 2011
                 Firmware Upgarde ( Engine: ver.004.001)
  Subject FS-3040MFP_FS-3140MFP_v.08.00.0020_(2011-02-07)
                 FS-3040MFP+_FS-3140MFP+_v.1.00.0030_(2011-04-14)
  Model          FS-3040MFP, FS-3140MFP

Topic
The firmware was upgraded as follows.


Content of Changes
                                                                                                                        CTL      FW
 No. Item                          Details
  1     Measures against the       The gray background may appear when refilling toner.                     566318            ENGINE

        gray background            The tolerance for gray background will be improved by regulating
                                   amount of the toner refilled when the toner cartridge is installed after
                                   [Replace toner] or [Low toner] appears.


The following has been changed since this engine firmware. Please explain it to the users.

"The toner container which displayed  once cannot be reused even if you reinstall it to the
machine. Please replace it with a new toner container."


                               Program No.         Check  Ver.            Status        Current        Remark
                                                    SUM                    Date          Ver.
 ENGINE                    2LW_1000.004.001        6EAA 004.001          2011/6/10      003.003                         New
                                                                                                                       upgrade
 MAIN                     2LW_2F00. 008.003                  008.003          -         007.010     FS-3040MFP
 MAIN                      2LX_2F00. 008.003                 008.003          -         007.010     FS-3140MFP
 SCANER                    2LW_1200.001.013                  001.013          -             -
 Optional language KR      2LW_81KR.001.014                  001.014          -             -       For KMKR
 Optional language TW     2LW_81TW.001.009                   001.009          -             -       For KMTW
 Optional language BR      2LW_81BR.001.015                  001.015          -             -       For KMBR
 Optional language CN     2LW_81CN.001.012                   001.012          -         001.010     For KTST
 FAX BOOT/APL              2H9_5500.006.001                  006.001          -         003.003     Except KTST
 FAX BOOT/APL              2H9_5700.N05.001                  N05.001          -         N04.002     For KTST


For the KM sales companies, it is possible to download the firmware at the download center on the ESDC.net.
When upgrading the firmware or replacing a board, please upgrade each kind of the firmware to the latest version at the same
time.


 KMC's Classification                 Entire Stock Rework                 In-Field modification at next visit
                                      In-Field modification by case        No modification necessary
  Field Measure: Please upgrade the firmware when the problem described above arises.
                   Also, please explain users on the content of  above.
  Serial Nos. of the Affected Machines: Planned from July 2011* production

                                *The above is the plan at the present moment. Please note that this information is subject to change.



                                              KYOCERA MITA Europe B.V.
                                     European Service & Development Center (ESDC)
