Image preview - the first page of the document



>> Download 2LW-001 documenatation <<

Text preview - extract from the document

                                      Service Bulletin
 SB Number: SB 2LW-001                                                                  Creation Date: 15/09/2010
 Subject:            Firmware upgrade
 Model:              FS-3040MFP/3140MFP


    Item                                       Contents
1   Trial based applications.                  When the date in the machine has been changed, the time to use trial
                                               based applications will be set to 0.
2   Error code CF248.                          Error code CF248 may occur when printing.
3   Machine does not reach "Ready"             Machines using KYOmulticode may not reach the "Ready" status when
    status.                                    the fax board is installed.


Firmware
Type                        Program No.               Check SUM             Version           Status Date         Applicable models
ENGINE                      2LW_1000.002.001          c43f                  002.001           04/06/2010          FS-3040MFP/3140MFP
MAIN                        2LW_2F00.002.007          ----                  002.007           ----------          FS-3040MFP
MAIN                        2LX_2F00.002.007          ----                  002.007           ----------          FS-3140MFP
FAX                         2H9_54000003003           ----                  -------           ----------          FS-3140MFP



Classification      Entire stock rework     In-field modification at next visit       In-field modification by case   No modification necessary
Field measure     When the above mentioned phenomena occur, please upgrade the firmware to the latest version.


Serial numbers of affected machines
Type                                      Serial number                                         Installed firmware
FS-3040MFP                                Q8E0600320                                            Main and engine
FS-3140MFP                           Q8L0701063                            Main and engine
Machines produced after the above mentioned serial numbers, should not have the above mentioned phenomena.




KMIS Service Department, Kyocera Mita Europe                       Page 1 of 1                                            A247 / SB 2LW-001
