Image preview - the first page of the document



>> Download 2LW-002 documenatation <<

Text preview - extract from the document

                                      Service Bulletin
 SB Number: SB 2LW-002                                                                    Creation Date: 15/09/2010
 Subject:            Firmware upgrade
 Model:              FS-3040MFP/3140MFP


Phenomenon          Error code C0180 may appear after replacing the main board.
Cause               The above mentioned phenomenon occurs when the serial numbers stored in the engine and
                    main board do not match.
Solution            Maintenance mode U004 (Setting the machine number) has been added, in order to change the
                    serial number in the engine board to the same number as in the main board.


Firmware
Type             Program No.              Check SUM Version                               Status Date           Applicable models
ENGINE           2LW_1000.002.001         c43f                  002.001                   04/06/2010            FS-3040MFP/3140MFP
MAIN             2LW_2F00.003.001 ----                          003.001                   ----------            FS-3040MFP
MAIN             2LX_2F00.003.001         ----                  003.001                   ----------            FS-3140MFP
FAX              2H9_54000003003          ----                  -------                   ----------            FS-3140MFP



Classification      Entire stock rework          In-field modification at next visit   In-field modification by case   No modification necessary
Field measure     When the above mentioned phenomenon occurs, please upgrade the firmware to the latest
                  version.



Serial numbers of affected machines
Type                                                                      Serial number
FS-3040MFP                                                                Not available
 FS-3140MFP                                           Q8L0701556
The above mentioned changes have been applied to machines produced after the above mentioned serial number.




KMIS Service Department, Kyocera Mita Europe                              Page  of                                         A258 / SB 2LW-002
