Image preview - the first page of the document



>> Download 2LW-008 documenatation <<

Text preview - extract from the document

                                        Service Bulletin
 SB Number: SB 2LW-008                                                                 Creation Date: 22/06/2011
 Subject:              Switching mistake of the envelope mode
 Model:                FS-3040MFP/3140MFP

Phenomenon            The switching button mismatch may occur when setting the fuser pressure to envelope mode.
Solution              When the above mentioned phenomenon occurs, please replace the Button fuser and
                      Button fuser B with the latest type.



         Fuser unit
                                                                Button fuser/Button fuser B specifications.




                                                                Cutting:120
                                                                                                Rib height has
                                                                degrees
                                                                                                been reduced from
         Button fuser B            Button fuser                                                 6mm to 5.5mm.
                                                                Height:
                                                                3.3mm.
         Old condition          New condition
                                                                0.9mm.
                                                                                               Thickness increased
                                                                                               by 0.6mm




Parts
No. Old Parts          New Parts            Description                                            Q'TY          Interchange-
    No.                No.                                                                                       ability
                                                                                                   Old    New Old        New
1       302J025051     302J025052           BUTTON FUSER                                           1      1      X       X
        2J025051       2J025052
2       302J025240     302J025241           BUTTON FUSER B                                         1      1      X       X
        2J025240       2J025241


Classification        Entire stock rework                     X In-field modification by case No modification necessary
                                                 In-field modification at next visit
Field measure     When the above mentioned phenomenon occurs, please replace the Button fuser and
                  Button fuser B with the latest type.


Serial numbers of affected machines
Type                                                                    Serial number
 FS-3040MFP/3140MFP                                   November 2010 production.
The above mentioned changes have been applied to machines produced after the above mentioned production date.


KMIS Service Department, Kyocera Mita Europe                            Page  of                              A378 / SB 2LW-008
