Image preview - the first page of the document



>> Download 2LW-013 documenatation <<

Text preview - extract from the document

                                      Service Bulletin
 SB Number: SB 2LW-013                                                                Creation Date: 06/12/2011
                     Firmware upgrade (Scanner v002.001 and Fax boot/APL
 Subject:
                     v007.002)
 Model:              FS-3040MFP/3140MFP



    Item                         Contents
1   Skipped parts of the         Phenomena
    image on the print-out.      If the DP is closed during scanning of the original, when the copy job is started, while
                                 opening the DP after placing the original on the contact glass, the following
                                 phenomena may occur:

                                 1. Only the leading edge of the image may appear on the print-out.
                                 2. Only the trailing edge of the image may appear on the print-out.

                                 This should not occur when copying with the DP.
2   Solenoid motion failure.     The DP reverse solenoid may not be released after completing Duplex scanning.




Firmware
Type                Program No.           Check SUM Version                   Status Date     Applicable model(s)
ENGINE              2LW_1000004001        6EAA                004.001         10/06/2011      FS-3040MFP/3140MFP
MAIN                2LW_2F00008003        ----                008.003         ----------      FS-3040MFP
MAIN                2LX_2F00008003        ----                008.003         ----------      FS-3140MFP
SCANNER             2LW_1200002001        ----                002.001         10/06/2011      FS-3040MFP/3140MFP
FAX BOOT/APL        2H9_5500007002        ----                007.002         ----------      FS-3140MFP
Note: Please upgrade all the firmware at the same time.




Classification      Entire stock rework                        X In-field modification by case No modification necessary
                                            In-field modification at next visit
Field measure     When the above mentioned phenomena occur, please upgrade the firmware to the latest
                  version.




Serial numbers of affected machines
Type                                                                   Serial number
 FS-3040MFP/3140MFP                                     October 2011 production.
The above mentioned changes have been applied to machines produced after the above mentioned production date.




KMIS Service Department, Kyocera Mita Europe                       Page 1 of 1                             B382 / SB 2LW-013
