                                       Service Bulletin
 SB Number: SB 2H9-019                                                              Creation Date: 06/12/2011
 Subject:             Error code C3100 due to the locked lock lever
                      FS-1028MFP/1128MFP, FS-3040MFP/3140MFP/3040MFP+/
 Model:               3140MFP+/3540MFP/3640MFP, FS-C2026MFP/2126MFP/
                      2026MFP+/2126MFP/2526MFP/2626MFP

Contents
The lock lever locks the ISU for transportation. When the lock lever is NOT released, error code C3100 (ISU
home position error) may occur when the power is turned ON when setting up the machine. Therefore, a leaflet to
instruct releasing the lock lever has been added.

Contents
Move the lock lever to the release position. When turning ON the power if the lock lever is not released, error
code C3100 (ISU home position error) may occur. Turn the power OFF and release the lock lever and turn the
power ON again if the above mentioned phenomenon occurs for this reason.




 Leaflet contents




 Leaflet location




   Lock lever                                                                                                     Leaflet


   Fixing tape
                                                                                                                  Scanner unit section




Classification       Entire stock rework    In-field modification at next visit              X No modification necessary
                                                                                  In-field modification by case
Field measure       Please release the lock lever before turning ON the machine during set-up.
