Image preview - the first page of the document
>> Download SB-2MF-0002-B381 documenatation <<
Text preview - extract from the document
(Page.1/1)
Service Bulletin Ref. No.2MF-0002 (B381)
November 10, 2011
Firmware Upgrade (MAIN: Ver.003.009; FAX: Ver.007.002;
Subject Optional Language: Ver.001.015 (KMKR), Ver.001.013 (KMTW))
FS-3040MFP+_FS-3140MFP+_v.3.00.0020_(2011-08-19)
Model FS-3040MFP+, FS-3140MFP+
Topic
The firmware was upgraded as follows.
Content of Changes
No. Item Details CTL No. FW
1 Support for Mexico The Mexican country code was added. 556269 FAX
2 565906 MAIN
Production line support Change was made in order to improve the assembly process.
3 605178 LAN
KMKR support Korean as optional language was added
4 LAN
KMTW support Traditional Chinese as optional language was added.
Check Status Current
Program No. SUM Ver. Date Ver. Remark
ENGINE 2LW_1000004001 6EAA 004.001 - 003.003
MAIN 2MF_2F00003009 003.009 - 003.008 FS-3040MFP+ New upgrade
MAIN 2MG_2F00003009 003.009 003.008 FS-3140MFP+ New upgrade
SCANER 2MG_1200001015 - 001.015 - 001.015
Optional language 2LW_81BR001017 - 001.017 - 001.015
BR
Optional language 2LW_81KR001015 - 001.015 - - For KMKR New firmware
KR
Optional language 2LW_81TW001013 - 001.013 - - For KMTW New firmware
TW
New upgrade
FAX BOOT/APL 2H9_5500007002 - 007.002 - 006.001
For the KM sales companies, it is possible to download the firmware at the download center on the ESDC.net.
When upgrading the firmware or replacing a board, please upgrade all kinds of the firmware to the latest version at the same
time.
KMC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: No particular problem is expected.
Serial Nos. of the Affected Machines: Planned from the October 2011* production
*The above is the plan at the present moment. Please note that this information is subject to change.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
