Image preview - the first page of the document
>> Download SB-2MF-0004-B461 documenatation <<
Text preview - extract from the document
(Page.1/4)
Service Bulletin Ref. No.2MF-0004 (B461)
December 27, 2011
Firmware Upgrade (Main: Ver.004.002; Optional Language
Subject Simplified Chinese: Ver.001.013; FAX: Ver.Z07.001 for KTST)
FS-3040MFP+_FS-3140MFP+_v.4.00.0010_(2011-11-17)
FS-3040MFP+, FS-3140MFP+, FS-3040MFP, FS-3140MFP,
Model
FS-1124MFP, FS-1128MFP
Topic
The firmware was upgraded as follows.
Content of Changes
These changes are only for the FS-3040MFP+ and FS-3140MFP+. As for the other models, the firmware was upgrade for
common use.
Change Details CTL FW
No.
609474
1 KTST support The simplified Chinese message was revised. 609349
LANG
2 Catalan support Catalan is now supported as a new optional language. 608357 MAIN
3 China Green mark support The default sleep timer for KTST was set to 1 minute. 609217 MAIN
FAX support for Chinese Chinese specs. FAX is now supported. (The new models
4 2KX-016 FAX CHN
specs. were added.)
For more details, please refer to the next pages.
FS-3040MFP+, FS-3140MFP+
Program No. Check Ver. Status Date Current Remark
SUM Ver.
MAIN 2MF_2F00004002 - 004.002 2011/10/17 003.009 FS-3040MFP+ New upgrade
MAIN 2MG_2F00004002 - 004.002 2011/10/17 003.009 FS-3140MFP+ New upgrade
ENGINE 2LW_1000005002 A1EC 005.002 - -
SCANNER 2MG_1200001015 - 001.015 - -
Optional 2LW_81BR001017 - 001.017 - - Brazilian
language BR Portuguese*
Optional 2LW_81KR001015 - 001.015 - - Korean for
language KR KMKR
Optional 2LW_81TW001013 - 001.013 - - Traditional
language TW Chinese for
KMTW
Optional 2LW_81CN001013 - 001.013 - - Simplified New upgrade
language CN Chinese for KTST
FAX 2H9_5500007002 - 007.002 - -
BOOT/APL
FAX 2H9_5500N07001 - N07.001 - - For KTST New upgrade
BOOT/APL
*Except KMKR, KMTW and KTST
For the KM sales companies, it is possible to download the firmware at the download center on the ESDC.net.
When upgrading the firmware or replacing a board, please upgrade all kinds of the firmware to the latest version at the same
time.
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.2/4)
Service Bulletin Ref. No. 2MF-0004 (B461)
December 27, 2011
KMC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: Please upgrade the firmware when the problem described above arises.
Serial Nos. of the Affected Machines:
FS-3040MFP+, FS-3140MFP+: Planned from the December 2011 production*
FS-3040MFP, FS-3140MFP: No production is planned.
FS-1124MFP, FS-1128MFP: After using up the old stock
*The above is the plan at the present moment. Please note that this information is subject to change.
FS-3040MFP, FS-3140MFP
Program No. Check Ver. Status Date Current Remark
SUM Version
MAIN 2LW_2F00008003 - 008.003 - - FS-3040MFP
MAIN 2LX_2F00008003 - 008.003 - - FS-3140MFP
ENGINE 2LW_1000005002 A1EC 005.002 - -
SCANNER 2LW_1200002001 - 002.001 - -
Optional 2LW_81BR001015 - 001.015 - - Brazilian
Language BR Portuguese*
Optional 2LW_81KR001015 - 001.015 - - Korean for
Language KR KMKR
Optional 2LW_81TW001013 - 001.013 - - Traditional
Language TW Chinese for
KMTW
Optional 2LW_81CN001013 - 001.013 - 001.012 Simplified New upgrade
Language CN Chinese for KTST
FAX 2H9_5500008001 - 008.001 - - Except KTST
BOOT/APL
FAX 2H9_5500N07001 - N07.001 - N06.002 For KTST New upgrade
BOOT/APL
*Except KMKR, KMTW and KTST
FS-1124MFP
Type Program No. Check VER. Status Date Current Remark
SUM Version
MAIN 2M0_2F00003002 - 003.002 - -
ENGINE 2L9_1000001001 - 001.001 - -
SCANNER 2L9_1200001001 - 001.001 - -
Option 2L9_81BR001001 - 001.001 - - Brazilian
Language BR Portuguese
Option 2L9_81PT001001 - 001.001 - - Portuguese
Language PT
Option 2L9_81CN001002 - 001.002 - - Simplified
Language CN Chinese for KTST
FAX 2H9_5500N07001 - N07.001 - N06.002 New upgrade
BOOT/APL
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.3/4)
Service Bulletin Ref. No.2MF-0004 (B461)
December 27, 2011
FS-1128MFP
Program No. Check Ver. Status Date Current Remark
SUM Ver.
MAIN 2JN_2F00024005 - 024.005 - -
ENGINE 2H9_1000005001 3eaf 005.001 - -
SCANNER 2H9_1200004001 - 004.001 - -
Optional 2H9_81BR001008 - 001.008 - - Brazilian
Language BR Portuguese
Optional 2H9_81KR001004 - 001.004 - - Korean for
Language KR KMKR
Optional 2H9_81CN001005 - 001.005 - - Simplified
Language CN Chinese for KTST
FAX 2H9_5500008001 - 008.001 - - Except KTST
BOOT/APL
FAX 2H9_5500N07001 - N07.001 - N06.002 For KTST New upgrade
BOOT/APL
No. Change Details CTL FW
Performance Printing a certain data was slow. Therefore, this was corrected. 576510 MAIN
5 TP-11-071
improvement UT-S11-014
Correction of the If Command Center message in an optional language was 389142 MAIN
TP-090138
6 optional language stored in a HDD, it was not correctly indicated during the sleep ESDC-0002
message failure mode. Therefore, this was corrected.
Measures against the The KPDL error occurred when a certain PDF file was directly 576546 MAIN
TP-090271
7 PDF direct print failure printed (Error Name: /undefinedresult, Offending Command: -- #786756
show--). Therefore, this was corrected.
Measures against the 608514 MAIN
Polish characters were garbled when a certain PDF file was
8 TP-090345
PDF direct print failure directly printed. Therefore, this was corrected. KMIS_LWIK-12901
Measures against the The KPDL error occurred when a certain PDF file was directly 576542 MAIN
TP-090354
9 PDF direct print failure printed (Error Name: /invalidrestore, Offending Command: -- #841518
restore--). Therefore, this was corrected.
Measures against the Part of letters was not printed when a certain PDF file was 608506 MAIN
10 TP-10-058
PDF direct print failure directly printed. Therefore, this was corrected.
Measures against the The Code39 barcode was not printed when a certain PDF file 608503 MAIN
11 TP-10-082
PDF direct print failure was directly printed. Therefore, this was corrected.
Measures against the Print failed and "PDFConversionError" report was printed when 608493 MAIN
TP-10-190
12 PDF direct print failure a certain PDF file was directly printed. Therefore, this was #1082064
corrected.
Measures against the The KPDL error occurs when printing a certain PDF data. (Error 608487 MAIN
13 TP-10-203
PDF direct print failure Name: /syntaxerror) Therefore, this is corrected. NP-Z10068
Measures against the Wrong characters were printed in a large font when a certain 608483 MAIN
14 TP-11-055
PDF direct print failure PDF file was directly printed. Therefore, this was corrected. KMA-D-1102-06
Measures against the The letters were garbled when a certain PDF file was directly 608474 MAIN
15 TP-11-149
PDF direct print failure printed. Therefore, this was corrected. KMA-SatPr110622
Measures against the The KPDL error occurred when printing a certain KPDL data. 608478 MAIN
16 TP-11-058
KPDL error Therefore, this was corrected. #1201170
Measures against the The KPDL error occurred when printing a certain PDF data. 608470 MAIN
17 TP-11-127
KPDL error Therefore, this was corrected. NP-Z11035
Measures against the 576526 MAIN
The "Processing" lock-up occurred when printing a certain PDF
TP-10-252
18 lock-up file from the Mac OS 10.6 Preview. Therefore, this was UTS-10-039
corrected.
Measures against the 608499 MAIN
The "Processing" lock-up occurred when a certain PCL data
19 TP-10-314
lock-up was sent. Therefore, this was corrected. #1160832
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
(Page.4/4)
Service Bulletin Ref. No. 2MF-0004 (B461)
December 27, 2011
The CF248 error occurred with a certain data. Therefore, this 608491 MAIN
Measures against the
20 TP-11-166
system error (CF248) was corrected. #1316019
Prevention of the 608595 MAIN
If the character codes 0x21, 0x52 and 0x21 (!R!) exist in
TP-11-046
Prescribe mode entry series in the PCL5 data, Prescribe mode was unintentionally NP-Z11006
21
entered and no data was printed after that. Therefore, this was
corrected.
Measures against the LF code might be ignored in the SMB protocol printing. 608754 MAIN
TP-11-109
22 SMB protocol printing Therefore, this was corrected. NP-Z1103
failure
Measures against the A certain file was not correctly printed if the KYOmulticode CF 608494 MAIN
TP-10-022
23 print failure with a card was inserted. Therefore, this was corrected.
certain file
"admin00" password ---------- 609113 MAIN
TO-11-003
24 support #1160788
#1160792
Preventive measure ---------- 609107 MAIN
TO-11-007
against overwriting of
25 #1160788
the Command Center
settings
KYOCERA MITA Europe B.V.
European Service & Development Center (ESDC)
