Image preview - the first page of the document



>> Download SB-2LW-0010-B316 documenatation <<

Text preview - extract from the document

                                                                                                               (Page.1/1)

           Service Bulletin                                                            Ref. No.2LW-0010 (B316)
                                                                                              September 21, 2011
                   Notes on Replacement of the FD UNIT SP
  Subject
                   (Bundling a Cable Tie for the Motor Wire)
                   FS-3040MFP, FS-3140MFP, FS-3140MFP+, FS-3040MFP+,
  Model
                   FS-3640MFP, FS-3540MFP
Topic
A cable tie and a leaflet are now bundled in FD UNIT SP in order to prevent the motor wire from being spread after
the FD UNIT SP was replaced.

[For more details on handling of the bundled cable tie, please refer to the bundled leaflet or the service bulletin SB-
2F8-0039-B272.]

*This change was referred in [Plan from now on] for the MFP products on the page 2 of the service bulletin SB-2F8-
0039-B272.


                                                                                          Com pati-
           Old Part       New Part                                          Q'ty            bi lity
  No.        No.            No.                   Description                                              Remarks
                                                                      Old New             Old New
         302LW94180      302LW94181
   1       2LW9180         2LW9181        PARTS FD UNIT SP              1          1       O     O    *1

   2     302MC94010      302MC94011       PARTS FD UNIT SP              1          1       O     O    *2
          2MC94010        2MC94011
                        7YZM420003++H01
   3           -          YZ052580        +ACCESS BAND                  -          1       -     O

*1: For FS-3140MFP and FS-3040MFP
*2: For FS-3140MFP+, FS-3040MFP+, FS-3640MFP and FS-3540MFP


[Reference]
              Bind the motor wire
              with the cable tie




Wires from neighboring boards

        FD UNIT (ASSY) motor wire
              Connect board R

                                          Correct state




 KMC's Classification               Entire Stock Rework                     In-Field modification at next visit
                                    In-Field modification by case            No modification necessary
  Field Measure: Please refer to the bundled leaflet or the service bulletin SB-2F8-0039-B272 when replacing
                   the FD UNIT SP.
  Serial Nos. of the Affected Machines: ----------


                                              KYOCERA MITA Europe B.V.
                                     European Service & Development Center (ESDC)
