Image preview - the first page of the document
>> Download SB-2LW-0013-C104 documenatation <<
Text preview - extract from the document
(Page.1/2)
Service Bulletin Ref. No. 2LW-0013 (C104)
April 18, 2012
Firmware Upgrade
(Engine: Ver. 2LW_1000.006.002/ 2MC_1000.004.002)
Subject FS-3040MFP_FS-3140MFP_v.08.00.0050_(2011-02-07)
FS-3040MFP+_FS-3140MFP+_v.4.00.0020_(2011-11-17)
FS-3540MFP_FS-3640MFP_v04.00.0040_(2011-10-25)
FS-3040MFP, FS-3140MFP, FS-3040MFP+, FS-3140MFP+,
Model
FS-3540MFP, FS-3640MFP
Topic
The firmware was upgraded as follows.
Content of Changes
No. Change Details CTL No. FW
Improvement of the The cassette size might be incorrectly detected depending on
630698
1 margins for cassette variation of the resistance or voltage. Therefore, the threshold of the 630700
ENGINE
size detection cassette size detection was changed.
Check Status Current
Type Program No. Ver. Remark
SUM Date Ver.
MAIN 2LW_2F00008003 - 008.003 - - FS-3040MFP
MAIN 2LX_2F00008003 - 008.003 - - FS-3140MFP
ENGINE 2LW_1000006002 99C6 006.002 - 005.002 New upgrade
SCANNER 2LW_1200002001 - 002.001 - -
Optional Brazilian
2LW_81BR001017 - 001.017 - -
Language Portuguese
Optional
2LW_81KR001015 - 001.015 - - Korean
Language
Optional Traditional
2LW_81TW001013 - 001.013 - -
Language Chinese
Optional Simplified
2LW_81CN001013 - 001.013 - -
Language Chinese
FAX BOOT/APL 2H9_5500008001 - 008.001 - -
FAX BOOT/APL 2H9_5700N08001 - N08.001 - - For KDCN
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
(Page.2/2)
Service Bulletin Ref. No. 2LW-0013 (C104)
April 18, 2012
Check Current
Type Program No. Ver. Status Date Remark
SUM Ver.
MAIN 2MF_2F00004002 - 004.002 2011/10/17 - FS-3040MFP+
MAIN 2MG_2F00004002 - 004.002 2011/10/17 - FS-3140MFP+
ENGINE 2LW_1000006002 99C6 006.002 - 005.002 New upgrade
SCANNER 2MG_1200001015 - 001.015 - -
Optional Brazilian
2LW_81BR001017 - 001.017 - -
Language Portuguese
Optional
2LW_81KR001015 - 001.015 - - Korean
Language
Optional Traditional
2LW_81TW001013 - 001.013 - -
Language Chinese
Optional Simplified
2LW_81CN001013 - 001.013 - -
Language Chinese
FAX BOOT/APL 2H9_5500008001 - 008.001 - -
FAX BOOT/APL 2H9_5700N08001 - N08.001 - - For KDCN
For the KDC sales companies, it is possible to download the firmware at the download center on the Service World.
When upgrading the firmware or replacing a board, please upgrade all kinds of the firmware to the latest version at the same
time.
KMC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: Please upgrade the firmware when the problem described arises.
Serial Nos. of the Affected Machines: Planned from the March 2012* production
*The above is the plan at the present moment. Please note that this information is subject to change.
CHECK Current
Type Program No. Ver. Status Date Remark
SUM Ver.
MAIN 2MC_2F00004004 - 004.004 2011/10/25 - FS-3540MFP
MAIN 2MD_2F00004004 - 004.004 2011/10/25 - FS-3640MFP
MMI 2MC_7000005001 - 005.001 - -
ENGINE 2MC_1000004002 72B6 004.002 - 003.002 New upgrade
SCANNER 2MC_1200003001 - 003.001 - -
Optional Brazilian
2MC_81BR001008 - 001.008 - -
Language Portuguese
FAX BOOT
2KX_5500007001 - 007.001 - -
APL
KYOCERA Document Solutions Europe
Technical Customer Service Division (TCSD)
