Image preview - the first page of the document
>> Download SB-2MC-0006-D110 documenatation <<
Text preview - extract from the document
(Page.1/2)
Service Bulletin Ref. No. 2MC-0006 (D110)
May 27, 2013
Subject Firmware Upgrade (Main Ver.007.005)
FS-3540MFP_FS-3640MFP_v07.00.0010_(2013-04-19)
Model FS-3540MFP, FS-3640MFP l:
KDC's Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: No particular problem is expected.
Serial Nos. of the Affected Machines: From the May 2013* production (Plan)
* The above is the plan at the present moment. Please note that this information is subject to change.
Topic
The firmware was upgraded as follows.
Content of Changes
No. CTL FW
Change Details
1 Additional maintenance 811608 MAIN
The following maintenance mode items were implemented:
mode items U001, U019, U034, U065, U066, U067, U068, U070, U071, U072,
U402, U403, U404
2 Support of ELATEC 656079 MAIN
The TWN4 Card Reader manufactured by ELATEC is now usable.
Card Reader (Readable card types for the TWN4 : TYPE A (Mifare)/ FeliCa/
LEGIC)
3 807439 MAIN
Felica-Lite support with Felica-Lite card is now usable with the SCM Card Reader.
the SCM Card Reader (Readable card types for the SCM: TYPE A (Mifare)/ TYPE B/ FeliCa/
FeliCa -Lite)
4 816436 MAIN
Support for the job ID Several pages might not be printed if the printer job ID was changed. TO-13-018,
change Therefore, this was corrected. #1633347
5 817773 MAIN
Measures against the Printing with MyQ might fail after printing several documents. TO-12-181,
print failure with MyQ Therefore, this was corrected. TA-S12-065
(MyQ: European
application)
Type Program No. Ver. Remark
MAIN 2MC_2F00007005 007.005 FS-3540MFP <--New Upgrade
MAIN 2MD_2F00007005 007.005 FS-3640MFP <--New Upgrade
MMI 2MC_7000006010 006.010
ENGINE 2MC_1000004002 004.002
SCANNER 2MC_1200004001 004.001
Optional Language 2MC_81BR001011 001.011 Brazilian Portuguese
FAX BOOT APL 2KX_5500008003 008.003 FS-3540MFP
For the KD sales companies, it is possible to download the firmware at the download center on the Service World.
When upgrading the firmware or replacing a board, please upgrade all kinds of the firmware to the latest version at the same
time.
KYOCERA Document Solutions Europe
Customer Services & Support Division (CSSD)
(Page.2/2)
Service Bulletin Ref. No. 2MC-0006 (D110)
May 27, 2013
No. Change Details CTL FW
6 Measures against the Characters of barcode garbled when printing a certain PCL data. 520582 MAIN
TP-10-318,
barcode print failure Therefore, this was corrected. KMA-D-
1012-05
7 The machine might lock up during data processing and the output data 580345 MAIN
Measures against the TP-11-218
machine lockup when using from the certain application might not be printed. Therefore, this was NP-Z11059
corrected.
a certain application
8 Measures against the Characters garbled when registering a certain macro data containing 638115 MAIN
TP-12-125,
garbled characters when the comment data of PCL5c. Therefore, this was corrected. #1466286
registering a certain macro
data
9 Measures against the wrong ---------------------- 565566 MAIN
TP-11-120,
fonts print when printing a #1271661
certain file
10 Measures against the font The font pitch was widened when printing the form created with the 656582 MAIN
TP-12-222,
pitch failure with a certain PCL macro overlaying in the print data, or the font pitch when printing KDA-D-
the data without calling macro and when printing it with macro was 1209-01
data
different. Therefore, this was corrected.
11 Measures against the SCM 646835 MAIN
The SCM card reader might not be recognized. Therefore, this was TO-12-097
card reader recognition corrected.
failure (The phenomenon above, however, can be recovered by
disconnecting and reconnecting the USB port.)
12 Prevention of the Prescribe If character codes were aligned in the order of [33],[82] and [33] in 539574 MAIN
TP-11-046
mode entry with a certain decimal (!R!) in the PCL5 data, the machine entered the prescribe NP-Z11006
mode unintentionally and no more data was printed after that.
file
Therefore, this was corrected.
13 Performance improvement Output was paused once in every few pages when a certain PDF file 794119 MAIN
TP-12-245,
with a certain PDF file was continuously printed, and print time became longer. Therefore, KDA-D-
this was corrected. 1210-02
14 Performance improvement The PCL data output from a user system (Print2000) was not output at 632581 MAIN
TP-12-082,
when printing data from the expected speed. Therefore, this was corrected. ESha12032
8-1
user system
15 Measures against the Line(s) appeared on output image when printing a certain PS data. 795887 MAIN
TP-12-254,
image failure with a certain Therefore, this was corrected. TA-S12-
053
file
16 Measures against the A part of fonts were not correctly printed with a certain print data. 656569 MAIN
TP-12-221,
font failure with a certain Therefore, this was corrected. #1525504
print data
KYOCERA Document Solutions Europe
Customer Services & Support Division (CSSD)
