Image preview - the first page of the document



>> Download SB-2MC-0001-B202 documenatation <<

Text preview - extract from the document

                                                                                                                          (Page.1/1)

           Service Bulletin                                                             Ref. No.   2MC-0001 (B202)
                                                                                                    July 11, 2011
                 Firmware Upgarde (Engine: Ver.002.001, Scanner: Ver.002.001)
  Subject
                 FS-3540MFP_FS-3640MFP_v03.00.0010_(2011-07-11)
  Model          FS-3540MFP, FS-3640MFP

Topic
The firmware was upgraded as follows.


Content of Changes
                                                                                                                       CTL.     FW
 No. Item                          Details
  1     Measures against the       The gray background might appear when refilling toner.                    566318 ENGINE
        gray background            The tolerance for gray background will be improved by regulating
                                   amount of the toner refilled when the toner cartridge is installed after
                                   [Replace toner] or [Low toner] appears.
  2     Measures against           The DP non-feed jam might occur in case that the timing switch to detect 564791 SCANNER
        the DP non-feed jam        the original was delayed due to its slippage. Therefore, the retrial time
        (JAM9000)                  for the timing switch was changed.
                                      Retrial time: 334msec        484msec




The following has been changed since this engine firmware. Please explain it to the users.

"The toner container which displayed  once cannot be reused even if you reinstall it to the
machine. Please replace it with a new toner container."




                           Program No.         Check        Ver.        Status       Current         Remark
                                                SUM                      Date         Ver.
 ENGINE                2MC_1000.002.001        F709       002.001      2011/6/1      001.008                          New upgrade
                                                                          0
 MAIN                  2MC_2F00. 001.041                  001.041          -             -       FS-3540MFP
 MAIN                  2MD_2F00. 001.041                  001.041                                FS-3640MFP
 SCANER                2MC_1200.002.001         FBB1      002.001      2011/5/2      001.017                          New upgrade
                                                                          5
 Optional language     2MC_81BR.001.004                   001.004         -              -       For KMBR
 BR
 FAX BOOT/APL           2KX_5500.005.003                  005.003          -                     FS-3640MFP


For the KM sales companies, it is possible to download the firmware at the download center on the ESDC.net.
When upgrading the firmware or replacing a board, please upgrade each kind of the firmware to the latest version at the same
time.



 KMC's Classification                 Entire Stock Rework                 In-Field modification at next visit
                                      In-Field modification by case        No modification necessary
  Field Measure: Please upgrade the firmware when the problem described above arises.
                   Also, please explain the users the content of  above.
  Serial Nos. of the Affected Machines: Scanner: From available timing in June 2011 production*
                                             Engine: Planned from the May 2011 production*
                                *The above is the plan at the present moment. Please note that this information is subject to change.
