Image preview - the first page of the document



>> Download SB-2MC-0002-B260_1 documenatation <<

Text preview - extract from the document

                   (Revised Issue 1)                                                                                         (Page.1/1)

             Service Bulletin                                                               Ref. No.   2MC-0002 (B260)
                                                                                                        August 26, 2011

  Subject Firmware Upgrade (Main: Ver.003.024)
                 FS-3540MFP_FS-3640MFP_v03.00.0010_(2011-07-11)
  Model          FS-3540MFP, FS-3640MFP,
   This time, the description with (-->) was revised from the previous information.
    The columns for the MMI firmware were added.

Topic
The firmware was upgraded as follows.


Content of Changes

 No. Item                      Details                                                                                       CTL    FW

   1 Support of Olivetti       ---------------                                                                                      MAIN


   2 Support for KMPM          Device license and Simple FollowMe Print (ReleaseAllJob) are now supported.                          MAIN


   3 POP/SMTP support          ---------------                                                                                      MAIN


   4 Equitrac support          ---------------                                                                                      MAIN




                           Program No.           Check  Ver.          Status        Current            Remark
                                                  SUM                  Date           Ver.
 ENGINE              2MC_1000.002.001            F709 002.001        2011/6/10      001.008
 MAIN                2MC_2F00. 003.024                   003.024          -         001.041     FS-3540MFP              New upgrade

 MAIN                2MD_2F00. 003.024                   003.024                    001.041     FS-3640MFP              New upgrade

 SCANER              2MC_1200.002.001            FBB1    002.001     2011/5/25      001.017

 (-->) MMI           2MC_7000.003.020              -     003.020          -             -

 Optional                                                                                       Brazilian
 language BR         2MC_81BR.001.006              -     001.006          -         001.004     Portuguese              New upgrade
                                                                                                (KMBR)
 FAX BOOT/APL        2KX_5500.005.003              -     005.003          -             -       FS-3640MFP


For the KM sales companies, it is possible to download the firmware at the download center on the ESDC.net.
When upgrading the firmware or replacing a board, please upgrade each kind of the firmware to the latest version at the same
time.




 KMC's Classification             Entire Stock Rework                In-Field modification at next visit
                                  In-Field modification by case       No modification necessary
  Field Measure: Please upgrade the firmware when the problem described above arises.

  Serial Nos. of the Affected Machines: Planned from the July 2011 production*
                                   *The above is the plan at the present moment. Please note that this information is subject to change.




                                                  KYOCERA MITA Europe B.V.
                                         European Service & Development Center (ESDC)
