Image preview - the first page of the document



>> Download 2MD-001 documenatation <<

Text preview - extract from the document

                                      Service Bulletin
 SB Number: SB 2MD-001                                                               Creation Date: 29/03/2012
 Subject:             Improper open left cover detection due to sunlight
 Model:               FS-3040MFP+/3140MFP+/3540MFP/3640MFP
Phenomenon           The message "Close Left Cover" may be displayed when the Left cover (Cover side) is closed.
Cause                Sunlight passes through the Left cover, resulting in misdetection by the Waste toner bottle
                     sensor.
Solution             1. The Sheet cover side L has been added to the Left cover.
                     2. Due to the above mentioned change, the shape of the Left cover and the Himelon sheet has
                        been changed.




               Parts cover side SP




               Old condition                                                        New condition
                                                                                                                     The shape
                                                                                                                     of the Cover
                                                                                                                     has been
                                                                                                                     changed




                                Himelon sheet                             Added Sheet cover side L        The shape of the
                                                                          (PET film, Colour: Black,       Himelon sheet has
                                                                          T=0.25MM)                       been changed

Parts
No. Old Parts         New Parts           Description                                                 Q'TY           Interchange-
    No.               No.                                                                                            ability
                                                                                                      Old     New Old         New
1       302MC94080 302MC94081 PARTS COVER SIDE SP                                                     1       1      X        O
        2MC94080   2MC94081

Classification      Entire stock rework                        X In-field modification by case No modification necessary
                                              In-field modification at next visit
Field measure      When the above mentioned phenomenon occurs, please replace the Left cover with the latest
                   type.

Serial numbers of affected machines
Type                                                                 Serial number
FS-3040MFP+/3140MFP+/3540MFP/3640MFP                                 Planned from March 2012 production*.
The above is the plan at the present moment. Please note that there is a possibility of change after giving this
information.

KMIS Service Department, Kyocera Mita Europe                         Page 1 of 1                                  C074 / SB 2MD-001
