                                         Service Bulletin
 SB Number:            SB AS-119                                  Issue Date: 30/04/2003
 Subject:              Supply of `Special Tool, Stapler' for field service
 Model:                DF-600 / DF-610


DF-600: KM-4530 / 5530 * / 6330 * (* = with special adjustment only: see SB AS-116)
DF-610: KM-4530 / 5530 / 6330



Please be informed that a part number for the `SPECIAL TOOL, STAPLER' is available.
Please order the `SPECIAL TOOL, STAPLER' with below part number if required.


Purpose
The `SPECIAL TOOL, STAPLER' is a jig that is used when replacing a stapler unit or when a stapling
malfunction occurs. Please refer to page 2 and later of this service bulletin for more details.




   `SPECIAL TOOL, STAPLER' (P/N: 3B868010)




Parts Table

       Part No.        Part No.                                  Q'ty        Interchange-
No.                                       Description
        OLD             NEW                                    old-new           ability
  1      ---------    3B868010    SPECIAL TOOL, STAPLER         -     1       -          O




                     KMIS Service Team, Kyocera Mita Europe                       5490 / SB AS-119
                                                                                                                           3B8/9-2

(3) Adjusting the stapler unit mounting position
Perform this operation when replacing a stapler unit or when a stapling malfunction occurs.
* Since the front stapler and the rear stapler in the finisher have the same construction, only the procedure for the front
  stapler is described below. Use similar procedure for adjusting the rear stapler.

Tool required for adjustment
