Image preview - the first page of the document
>> Download DF-068 documenatation <<
Text preview - extract from the document
Service Bulletin
SB Number: SB DF-068 Creation Date: 16/04/2009
Additional service call C-8140 reason/measure (main tray
Subject:
problem)
Model: DF-71/710
Affected models: DF-71: FS-9100DN/9120DN/9500DN/9520DN
DF-710: FS-9130DN/9530DN
Contents of Service call C-8140 (main tray problem) reason/measure are described on page 46 of the
changes service manual.
Please note that service call C-8140 also occurs, when spring, holder main eject pull 303C106062
comes off from spring holder sol 303JY28340.
Fig. 4 Exit section
spring, holder main eject pull
303C106062
spring holder sol
303JY28340
KMIS Service Department, Kyocera Mita Europe Page 1 of 1 8741 / SB DF-068
