Image preview - the first page of the document



>> Download 3JY-001 documenatation <<

Text preview - extract from the document

                                                        Service Bulletin
 SB Number: SB 3JY-001                                                   Creation Date: 03/08/2006
 Subject:            Remarks when replacing a SPACER FINISHER
 Model:              DF-710
To improve the production process for the SPACER FINISHER, the new and old parts are no longer interchangeable.

Contents of change
When fixing the SPACER FINISHER, it should be fixed by PIN CONNECTER, instead of a SCREW and a WASHER.
Due to the above change, the shape and measurements of the SPACER FINISHER is changed.




          OLD SITUATION                                               NEW SITUATION

                                     SCREW
                                     WASHER




                                                                                        PIN CONNECTOR


                  7.5 MM                                                    4.9 MM




                                                                                                 Interchange
                                                                                              Q'ty  ability
No.     Old parts number          New part number                  Description
                                                                                         Old New Old      New
           303JY02470                303JY02471
 1                                                       SPACER FINISHER                  2          2        X      O
            3JY02470                  3JY02471
        5MBTPB3014TW++R              302FB08462
 2                                                       PIN CONNECTOR                    2          2        X      X
            B1A53140                  2FB08462

 3          C2604080                     ------------    PLAIN WASHER M4-8 (BRASS,N:)     2          -        X      -



Field Measure:
When replacing the parts, please use the new part `PIN CONNECTOR' only to fix the new SPACER FINISHER (Do
not affix the old SPACER FINISHER).

This change will take affect from:
The production in August, 2006


KIMS Service Team, Kyocera Mita Europe                                                                   7659 / SB 3JY-001
