Service Bulletin
SB Number: SB DF-060_Revised issue 2 Creation Date: 05/11/2008
Firmware change, new model support (Added correct item
Subject:
codes)
Model: DF-710/730, DP-710
Affected models: KM-C2520/3225/3232/2525E/3232E/4035E, KM-3050/4050/5050
Contents of 1. The firmware for DF-710 and DP-710 has been changed to support KM-C4035E.
changes 2. The firmware for DF-730 has been changed to support KM-2560/3060/2540/3040 and
KM-C4035E.
3. The below table describes the compatibility between current and new machines/accessories.
The newer DF-710/730 and DP-710 are compatible with the KM-C4035E.
Compatible with present model Support for new model
Main body to KM-C2520/C3225/C3232 KM-C4035E
which it can KM-C2525E/C3232E DF 730 supports KM-2560/3060/2540/3040.
be installed
Label on the
outer carton
DF-710 DF-730 DP-710 DF-710 DF-730 DP-710
Item code 1203JY0UN0 1205H10UN0 1203J95JP0 1203JY0U10 1205H10U10 1203J95J10
DF-710 parts No. Old Parts New Parts Description Q'ty Interchange- F/W
No. No. ablity version.
Old New Old New
1 303JY01022 303JY01023 MIDDLE PWB ASS'Y 1 1 X O 3JY_9600.
3JY01022 3JY01023 004.002
2 303JY80014 303JY80015 MAIN PWB ASS'Y 1 1 X O 3JY_9200.
3JY80014 3JY80015 WITH SOFTWARE SP 006.003
DP-710 parts No. Old Parts New Parts Description Q'ty Interchange- F/W
No. No. ablity version.
Old New Old New
1 303J901011 303J901012 DRIVER PWB ASS'Y 1 1 X O 3J9_9500.
3J901011 3J901012 004.005
DF-730 parts No. Old Parts New Parts Description Q'ty Interchange- F/W
No. No. ablity version.
Old New Old New
1 305H180020 305H180021 PBA-CONT-F 1 1 X O 5H1_9200.
5H180020 5H180021 002.007
Classification Entire stock rework In-field modification at next visit X In-field modification by case No modification necessary
Field measure Please make sure to note the contents above.
KMIS Service Department, Kyocera Mita Europe Page of 2 8095 / SB DF-060
Service Bulletin
Affected serial Type Item code Serial number
numbers DF-710 1203JY0U10 PRA7508105 and higher
1203JY3U10 PNP7502090 and higher
DF-730 1205H10U10 URF7412474 and higher
PRK******1 and higher
1205H13U10 UNN******1 and higher
PNX******1 and higher
DP-710 1203J95J10 PVM7507511 and higher
1203J90K10 PAQ7517537 and higher
1203J93U10 PNN7503761 and higher
Contents Model Item Contents
of firmware 1 DF-710 Support for KM-C4035E. Changed the conveying speed.
changes DF-730
DP-710
2 DF-710 The timing of paper holding In order to reduce the sound of the paper holding lever
solenoid has been adjusted. hitting the main tray, the operation timing of the paper
holding solenoid has been changed.
3 DF-710 Method to prevent JAM 88 There is a possibility that JAM88 might occur when
(Main tray eject JAM). copying 3 sheets monochrome A4 copies with 2
staples continuously.
4 DP-710 The paper feeding timing When using the Auto select function, there is a
when using the Auto select possibility that small sized originals are detected as
function has been changed. large sized originals and the copy image is printed half
on the large sized paper.
KMIS Service Department, Kyocera Mita Europe Page 2 of 2 8095 / SB DF-060
