Image preview - the first page of the document



>> Download DF-070 documenatation <<

Text preview - extract from the document

                                      Service Bulletin
 SB Number: SB DF-070                                                              Creation Date: 26/04/2010
 Subject:            Firmware upgrade (Damaged single booklet sheets)
 Model:              DF-710/BF-720


Affected models: BF-710: DF-710: FS-C8100DN+, FS-9130DN/9530DN
                 BF-720: DF-720: FS-C8500DN



Item             Contents
Damaged          Phenomenon
single sheet     Single folded sheets may be damaged when ejected by the finisher, depending on the paper type.
folded paper.
                 Cause
                 The ejection speed by the booklet rollers is faster than the speed of the booklet blade.
                 This increases the load on the paper.

                 Solution
                 The ejection speed of the booklet rollers has been changed from 60mm/s to 90mm/s to synchronize
                 the speed between the booklet rollers and the booklet blade.




                                                                 Booklet rollers




                                                                Booklet blade




Classification      Entire stock rework                       X In-field modification by case No modification necessary
                                           In-field modification at next visit
Field measure     When the above mentioned phenomenon occurs, please replace the main PWB with the latest
                  type.



KMIS Service Department, Kyocera Mita Europe                      Page  of 2                           A094 / SB DF-075
                                   Service Bulletin

Parts
No. Old Parts        New Parts      Description                                    Q'TY         Interchange- SP
    No.              No.                                                                        ability
                                                                                   Old    New Old       New
1       303J180012   303J180013     MAIN PWB ASS'Y WITH SOFTWARE SP                1      1     X       O       O
        3J180012     3J180013       (Version 3J1_9700.003.002)
2      303J101012 Changed to        MAIN PWB ASS'Y                                     1      1   X      O       O
       3J101012     new No.1 *1)
Part 1 and 2 have been unified, since the only difference is that part 1 does not contain the EEPROM and part 2 does
contain the EEPROM.


Serial numbers of affected machines
Type                                                      Serial number
BF-710                                                    PRF6X02530
 DF-710                                               PRA6X08114
The above mentioned changes have been applied to machines produced after the above mentioned serial numbers.




KMIS Service Department, Kyocera Mita Europe               Page 2 of 2                              A094 / SB DF-075
