Image preview - the first page of the document



>> Download 3JY-002 documenatation <<

Text preview - extract from the document

                                                                 Service Bulletin
 SB Number: SB 3JY-002                                                                           Creation Date: 01/06/2007
 Subject:                    Firmware change, new model compatibility chart
 Model:                      DF-710/730, DP-710
 The F/W is changed to support the new models, specifically the KM-C4035E.


 NOTE:
 The below table describes the compatibility between current and new machines/accessories. It becomes clear that only the new DF-710/730 and
 DP-710 are compatible with the new KM-C4035E. The new DF/DP models are compatible with all the current and new colour MFP's, whereas the
 current DF/DP rnage will cover all but one model; the KM-C4035E.



                               Compatible with present model                                            Support for new model
 Main body to
                     KM-C2520/C3225/C3232                                             KM-C2520/C3225/C3232
 which it can be
                     KM-C2525E/C3232E                                                 KM-C2525E/C3232E/C4035E
 installed

 Label on the
 outer carton

                             DF-710             DF-730                 DP-710                  DF-710            DF-730            DP-710
       Item code:          1203JY0UN0        1205H10UN0          1203J90KL0                1203JY0U10          1205H10U10        1203J90K10



Related part information

                                                                                                 Interchange
                                                                                    Q'ty
 No. Old part number          New part number            Description                                ability                 Remarks
                                                                                Old    New       Old    New

  1      303JY01022             303JY01023       MIDDLE PWB ASS'Y               1          1      X      O      F/W VER. 3JY_9600.004.002

                                                 MAIN PWB ASS'Y
  2      303JY80014             303JY80015                                      1          1      X      O      F/W VER. 3JY_9200.006.003
                                                 WITH SOFTWARE SP

  3       303J901011            303J901012       DRIVER PWB ASS'Y               1          1      X      O      F/W VER. 3J9_9500.004.005

  4      305H180020                   TBA        PBA-CONT-F                     1          1      X      O      F/W VER. 5H1_9200.002.007


Contents of change in firmware

      Model         Item                          Contents
      DF-710        Support for new model         Changed to support cycle speed of the KM-C4035E
      DF-730        (KM-C4035E)
 1
      DP-710

 2    DF-710        The timing of paper           In order to reduce the sound of the paper holding lever hitting the main tray, the
                    holding solenoid has been     operation timing of the paper holding solenoid has been changed as follows
                    adjusted
 3    DF-710        Measure against JAM 88        There might be the possibility that JAM88 might occur when copying 3 sheets
                    occurring due to 3 sheets     Monochrome A4 copy & 2 staples continuously. Therefore, it is corrected.
                    monochrome A4 & 2
                    staples (JAM88: Main tray
                    eject JAM)

 4    DP-710        The paper feeding timing      On the Auto Selection mode, there is a possibility that small size original is detected
                    at Auto Selection mode        as large size original and paper is output with half of the image printed on large
                    has been changed.             sized paper. Therefore, it is corrected.


KMIS Service Team, Kyocera Mita Europe                                                                                        8095 / SB 3JY-002
