                                   Service Bulletin
 SB Number: SB PF-019                                                    Creation Date: 15/09/2010
 Subject:            Error code CS1020 due to the damaged CPU of the main board
 Model:              PF-500/510


Affected models: PF-500                 FS-C5100DN/5200DN/5300DN/5350DN/5400DN
                     PF-510             FS-C5100DN/5200DN/5300DN/5350DN/5400DN



Phenomenon          Error code CS1020 (PF lift motor error) may occur.
Cause               The CPU may be damaged due to over-current or over-voltage, when the connection between
                    the paper feeder and the machine is interrupted.
Solution            The diode has been added to the circuit around the CPU to prevent damage to the CPU during
                    hot-swapping of this connection.




        PF-500




           PWB PF main with software (viewed from the back)




                                                                            Position of the added diode.




KMIS Service Department, Kyocera Mita Europe              Page 1 of 2                             A298 / SB PF-019
                                      Service Bulletin

Parts
No. Old Parts        New Parts            Description                          Q'TY            Interchange- SP            Applicable unit
    No.              No.                                                                       ability
                                                                               Old    New Old            New
1       303K801010 303K801011             PWB PF MAIN ASSY WITH 1                     1        O         O           O    PF-510
        3K801010   3K801011               SOFTWARE
2       303K901010 303K901011             PWB PF MAIN ASSY WITH 1                     1        O         O           O    PF-500
        3K901010   3K901011               SOFTWARE



Classification      Entire stock rework        In-field modification at next visit   In-field modification by case   No modification necessary
Field measure     When the above mentioned phenomenon occurs, please replace the main board (PWB PF main
                  assy with software) with the latest type.



Serial numbers of affected units
Type                                                                  Serial number
 PF-500/510                                           August 2010 production
The above mentioned changes have been applied to machines produced after the above mentioned production date.




KMIS Service Department, Kyocera Mita Europe                          Page 2 of 2                                          A298 / SB PF-019
