Image preview - the first page of the document



>> Download 2GR-032 documenatation <<

Text preview - extract from the document

                                        Service Bulletin
 SB Number: SB 2GR-032                                                              Creation Date: 01/10/2009
 Subject:              Common use of parts at the paper cassette
                       KM-3050/4050/5050, KM-C2520/3225/3232/2525E/3232E/4035E,
 Model:
                       PF-700/710


Affected          PF-700: KM-3050/4050/5050
models            PF-710: KM-C2520/3225/3232/2525E/3232E/4035E




Phenomenon        To make the parts at the paper cassette common with other models, the following changes have
                  been made:

                  1. The material of the cursor C cassette 302H009110 has been changed from metal to plastic.
                  2. The paper guide lines at the label paper size R1 302FZ09141 have been shifted 3mm to the
                     right, due to the increased thickness of the new cursor C cassette.
                  3. Based on the above mentioned changes, the following parts have been discontinued:
