>> Download RampRate QuasiCVAppNote1 documenatation <<

Text preview - extract from the document

                                          Number 2973


Application Note                         Using the Ramp Rate Method for Making
           Series                        Quasistatic C-V Measurements with the Model
                                         4200-SCS Semiconductor Characterization System

Introduction
                                                                                         I         Capacitor
Capacitance-voltage (C-V) measurements are generally made
using an AC measurement technique. However, some capacitance
                                                                          Force HI                                           Force HI
measurement applications require a DC measurement technique.
These are called quasistatic C-V (or QSCV) measurements
because they are performed at a very low test frequency, that is,
                                                                                                                         A
almost DC. These measurements usually involve stepping a DC
voltage and measuring the resulting current or charge. Some of                               V
the techniques used for quasistatic C-V measurements include
the feedback charge method and the linear ramp method.
The Model 4200-SCS Semiconductor Characterization System
uses a new method, the ramp rate method, which employs two
Model 4200-SMUs Source-Measure Units (SMUs) with two Model                                         Force LO
4200-PA PreAmps. The optional 4200-PA PreAmps are required                                   internally connected
because this test involves sourcing and measuring current in                     SMU1                              SMU2
the picoamp range. The SMUs are used to source current to                      ForceSMU                          MeasureSMU
charge the capacitor, and then to measure the voltage, time, and
discharge current.                                                  Figure 1. Connections for Capacitance Measurements Using
                                                                    Ramp Rate Method
    The software calculates the capacitance as a function of
voltage from the measured parameters and shows the curve on                      dQ
                                                                             C =
