Image preview - the first page of the document
>> Download 4434_Maximize_Accuracy documenatation <<
Text preview - extract from the document
Selecting Telecommunication Test Equipment To Maximize Throughput
and Accuracy
By Robert Green
Keithley Instruments, Inc.
Soaring demand for cell phones, pagers mobile radios and base-stations, is
putting pressure on test engineers to shorten production test time. This may
require selection of new test equipment that can improve throughput and
accuracy in several areas, including a wide variety of DC and low-frequency
board-level tests, and battery testing or simulation.
Battery Characteristics
To test portable communication devices under realistic conditions, you may need
a power supply that can simulate a battery under various discharge states. This
requires a power supply with a variable output impedance, which closely
duplicates the voltage characteristics of a battery during energy drain. These
power supplies should also have an ultra-wide bandwidth output stage to
minimize transient voltage droop and recovery time to allow end-of-life
rechargeable battery testing. In addition to accurate battery simulation, it is very
helpful to have a read-back power supply that can accurately measure load
currents. This eliminates the need for a separate instrument and calculation of
dynamic power consumption for comparison to test specs.
The Keithley Instruments Models 2302 and 2306 are typical of this new breed of
power supply specifically designed for portable telecommunication product
testing. The 2306 even has a second channel that allows seamless transfer of
power from the units battery channel to its charger channel while keeping the
device under test (DUT) powered. This allows accurate simulation of a DUTs
battery/power supply circuit as it switches to the charger when battery voltage is
low, thereby allowing realistic testing of the DUT under these conditions.
Switching Systems for Board Testing
The principal board-level tests on wireless devices are internal voltages, current
drains and power consumption. To speed up multiple measurements, a typical
test configuration includes automated signal routing equipment that ties different
instruments to several points on the DUT. However, the test system designer
must balance throughput and accuracy by selecting the appropriate switching
system.
Figure 1. Simplified diagram of a cell phone test system using a matrix switch
configuration. (A multiplexer topology also could be used; see text.)
When you consider the number of signal connections made through the
switching system (Figure 1), it becomes apparent that switching consumes a
major portion of test cycle time. Several design factors affect switching time:
Switch Configurations The current trend in switching system designs is to use
one or two basic topologies. The most common ones are the 1 x m multiplexer
and the n x m matrix, where the number of inputs, n, is switched to any one of
the m outputs. Multiplexer designs are easiest to construct and usually are the
most cost effective. However, overall throughput may benefit from a matrix
design, since any row can be connected to any column at any time.
Figure 2 shows two common types of multiplexers. The standard multiplexer
consists of a simple design that uses 1 x m relays (Figure 2a,) or a combination
of smaller relays, and works well at low frequencies. For large values of m and
high frequencies, the unterminated stubs may introduce signal degradation due
to reflection effects. An improved design utilizing tree switching (Figure 2b)
eliminates stubs but introduces additional relays and insertion loss into the signal
path and increases system cost.
Figure 2. Multiplex configurations: (a) 1 x 4 multiplex using a single 1 x 4 switch
(b) 1 x 8 multiplex using seven 1 x 2 switches in a tree configuration
Multiplexing can be done with relays or solid-state switching devices. Solid state
switches tend to have settling times of a few hundred microseconds; reed relay
settling times typically range from three to 10 milliseconds, but cost less.
Switching devices are normally installed on a switch card housed in the card
cage of a mainframe that also includes drive lines and test instruction
parameters. The system may connect these devices through several ports, such
as external trigger lines, input/output signals, and remote control connections
(GPIB, RS-232, etc.). See Figure 1.
Switching Times Switching time is another important specification. It is the time
it takes to disconnect one signal and connect another one to the measurement
instrument. Total switching time is a combination of trigger execution time,
actuation time and settle time. (Figure 3.)
Figure 3. The majority of a multiplexers switching time is the combination of the
time it takes for contacts to move across the switch gap (actuation time) and the
time it takes for contact bounce to stop (settle time.)
Along with switching time, a major consideration is the bandwidth of the signal
path. A lot of new switch cards have recently come to market with broadband
capabilities. However, keep in mind the rule that bandwidth costs money, which
applies to RF switching systems as well as other signal propagation systems.
Specify only what you need.
Measuring Instruments
Typically, production testing is computer controlled with individual instruments
and the switching system connected to a PC on the IEEE-488 bus. The test
setup may also involve the use of a device handler with a fixture that holds the
DUTs. A device handler can consume up to 100 ms during unloading and loading
of a DUT. As discussed earlier, the switching system can consume several
milliseconds for each actuation. Modern GPIB instruments can perform
measurements at rates as high as 2000 readings per second, or about 0.5
ms/reading. The IEEE-488 bus can transfer data at about 1 Mb/s, so it is least
likely to limit test system throughput.
There will be circumstances when factors other than speed affect instrument
selection criteria. Most often, accuracy will be a major consideration. Look for
programmable instrument features that allow accuracy and measurement speed
tradeoffs, such as the following:
Integration Rate. This is the time it takes the instruments A/D converter to look at
the input signal. The integration time affects the usable measurement resolution,
the amount of reading noise, and the ultimate reading rate of the measurement.
The optimum integration time setting involves a tradeoff between speed and
common mode or normal mode noise. If speed is the most important
consideration, then a small integration rate is used, such as 0.01 power line
cycles (PLCs), at the expense of reading additional noise and getting less usable
resolution. The greatest noise reduction is achieved by using integer PLC values.
Ranging. Instrument measurement rates are usually stated for a fixed
measurement range While some instruments have fast autoranging features,
actual speed is not predictable. If the feature is programmable, autoranging
should not be used when optimum speed is required; a fixed range is the only
way to ensure timing precision.
Filters. When digital filters are available, measurement rates are typically stated
with all filters turned off. Although filtering improves noisy measurements, it also
slows the rate of measurement. With a digital filter, an instrument takes a number
of A/D conversions and averages them before displaying the result. The greater
the number of conversions averaged, the slower the measurement rate.
Autozero. During autozero the A/D conversion is switched through four distinct
periods: signal integrate, reference integrate, zero integrate and calculate. With
autozero disabled, the A/D conversion does not use the zero integrate or
reference integrate periods and measurement speed is increased. However, it
also means the readings could drift slightly after a period of time. Assuming that
a small amount of drift can be tolerated over several measurements, then you
can program the instrument to autozero only at the start of a test cycle,
Trigger Delay. This is the period between the leading edge of the trigger signal
and the time when the instrument starts the A/D conversion. This delay is used
when signals have significant settling times, for example, in a multi-channel test
system with relays used to make connections to various inputs. Starting the A/D
conversion before the signal is settled could result in a noisy, inaccurate
measurement. By reading the relay or switching system spec sheet, you can
determine maximum settling time and program the trigger delay so it is only as
long as necessary.
Display. Updating an instruments front panel display takes time. In applications
where speed is critical, the display should be disabled, particularly in applications
where you only need a digital pass/fail signal at the end of each test.
Besides programmability, there are advantages to storing as much of the test
sequence as possible in instrument memory. Some instruments are designed to
store up to 100 or more test configurations. By calling up the test sequence from
instrument memory, external bus traffic between the host PC and the instrument
is kept to a minimum. This shortens the data transmission part of the test cycle.
Using an instrument with a comparator circuit and sending only a pass/fail signal
as mentioned above, instead of actual measurement values, reduces
transmission time and total test time even more.
About the Authors
Robert Green is Telecommunications Market Development Manager at Keithley
Instruments, Inc. in Cleveland, OH. For information on Keithley products, call
800-552-1115 or 440-248-0400, or visit www.keithley.com.
