KPCI-3160
Logic Inputs and Outputs                                                                                 Board Address Mapping
SYMBOL     PARAMETER                                         MIN.        TYP.     MAX.       UNIT        No jumper placed on REG-MAP-SEL yields register map A. (DEFAULT)
 VIH       Voltage, Input High                                2.0         --        --         V         There are 4 data groups with 4 control bytes. Each control byte is part of
 VIL       Voltage, Input Low                                 --          --        0.8        V         the corresponding 32 bit data word.
 IIH       Current, Input High, VIN = 2.7V                    --          --
