Image preview - the first page of the document



>> Download KPCMCIA-PIO24-C_DS documenatation <<

Text preview - extract from the document

                                                          KPCMCIA-                              24-Line Parallel Digital I/O Board
                                                          PIO24-C

                                                                                                The KPCMCIA-PIO24-C is a digital I/O PCMCIA                     Specifications
                                                                                                card for use with notebook and other PCs
                                                                                                equipped with a PCMCIA port. This card is ideal                 BUS TYPE: PCMCIA Type II. PC Card Standard 2.1 compliant.
                                                                                                for applications that demand alarm monitoring                   PHYSICAL DIMENSIONS: Type II PCMCIA card (5mm).
                                                                                                and parallel communication in field and labora-                 DIGITAL INPUT & OUTPUT: TTL compatible.
Ideal for alarm monitoring and parallel communication




                                                                                                tory environments where space is at a premium                   INPUT/OUTPUT CURRENT: 25mA maximum.
                                                                                                or portability is required. The KPCMCIA-PIO24-C                 CURRENT SOURCE/SINK:
                                                                                                                                                                  Sink: 6mA min. @ 0.33V.
                                                                                                features 24 TTL/DTL-compatible digital I/O lines,                 Sink: 20mA max. @ 1.0V.
                                                                                                each of which is buffered to enhance the card's                   Source: 1.1mA max. into 0 at Vcc = 5V.
                                                                                                drive capability. The card has an external inter-               OPERATING TEMPERATURE: 0
