Image preview - the first page of the document
>> Download Acc_Other documenatation <<
Text preview - extract from the document
other accessories
remote Preamp Mounting Carrying Case Test boards
accessories
Cabinets, other accessories
Cabinets, other accessories
Model 4200-MAG-BASE: Magnetic base for Model 8010-CTB: Customizable test board.
mounting the Model 4200-PA remote PreAmp
option onto a probe station platen . for use with: 8010
for use with: 4200-sCs
Model 4200-CASE: Transport case for
4200-SCS .
Model 4200-TMB: Triax mounting bracket for for use with: 4200-sCs
mounting the Model 4200-PA remote PreAmp
option onto a probe station or onto the triax remote Displays
mounting panel of a text fixture .
for use with: 4200-sCs
Model 8010-DTB: Device test board for
TO-247 devices (3kV, 100A).
for use with: 8010
Model 2304-DISP: LCD remote display with
keypad .
for use with: 2303, 2304a
Model 4200-VAC-BASE: Vacuum base for mount-
ing the Model 4200-PA remote PreAmp or Model
4225-RPM onto a probe station platen .
for use with: 4200-sCs
Model 8010-DTB-220: Device test board with
TO-220 socket (1.5kV).
for use with: 8010
ACCESSORIES
Model 2306-DISP: VFD remote display with
keypad .
for use with: 2302, 2306, 2306-Vs, 2308
1.888.KEITHLEY (U.S. only)
www.keithley.com
A Greater Measure of Confidence
