Image preview - the first page of the document
>> Download Acc_Bench-Rack-Cab documenatation <<Text preview - extract from the document bench Kits, rack Mount Kits
sElECTor GuIDE: raCK MouNT KITs
Instrument single fixed single slide1 Dual fixed Type of Mount
Series 2000 2700 6487 4288-22 Side
2182A 2701 6514 4288-43 Shelf
Series 2300 6220 4288-1 4288-54 Shelf
Series 2200 6221 6517B 4288-94 Shelf
Series 2500 6485 7001 4299-7 Side
Series 2100 Series 2400 6430 4299-3 4299-4 Side
4299-1
Series 2600B 4299-2 Side
4299-6
2750, System 46, System 46T 4288-7 Rear bracket
Model 2000-Benchkit: Benchtop Restore Kit . Series 3700A 4288-10 Rear bracket
Bench kits, rack mount kits
Bench kits, rack mount kits
Rubber feet and carrying handles are removed 248 248-RMK-1 248-RMK-2 Side
during rack mounting . These items can be used 707B Included 7079 Side
with any of the following models to convert it 708B Included Side
back to a benchtop instrument . 4200-SCS/C or /F 4200-RM
for use with: series 2000, 2182a, series 2300, 7002 7002-RMK-1 7002-RMK-2 Bracket w/handles
series 2400, series 2500, series 2600b, 2700, NoTEs
2701, 6220, 6221, 6430, 6482, 6485, 6487, 1 . Slide rack mount kits are not compatible with equipment cabinet Models 8000-10, 8000-14, and 8000-17 .
6514, 6517a, 6517b, 7001 2 . Model 4288-2 mounts any two of the listed models, except 776 .
3 . Model 4288-4 mounts: ANY ONE plus ANY ONE
230, 230-1 428-PROG, Series 2000, 2182A, Series 2300, Series 2400, Series 2500, 2700, 2701,
6220, 6221, 6430, 6485, 6487, 6514, 6517A, 6517B, 7001
4 . Models 4288-5 and 4288-9 mount any one or two of the listed models on a shelf-type mount .
Model 248-RMK-* Fixed Rack Mount Kit:
Enables rack mounting of Model 248 .
248-RMK-1 rack mounts one Model 248 .
248-RMK-2 (not pictured) rack mounts two
Model 248s side by side .
for use with: 248
Model 4200-RM: Fixed rack mount kit for cabi-
net mounting of the 4200-SCS .
for use with: 4200-sCs
Model 4288-2 Fixed Rack Mount Kit: Height:
88mm (3
