Image preview - the first page of the document



>> Download pa702a-Model_4200-TRX-X documenatation <<

Text preview - extract from the document

                                             Model 4200 TRX-X Triax Cable Assembly
                                                                       Packing List


Description
The Model 4200-TRX-X Triax Cable connects the installed 4200-PA (Preamplifier) in the Model 4200-SCS (Semiconductor
Characterization System) to the device under test (DUT).
Model 4200-TRX-X (Figure 1) consists of standard triax cable terminated with a standard 3-slot male triax connector on
each end.
One end connects to the FORCE connector on the 4200-PA installed in the system. The other end connects to the test fixture or
probe station holding the DUT.
The 4200-TRX-X is available in four lengths. The -X in the model number represents the cable length in meters,
as listed in Table 1.

                                        Table 1
                                        Cable lengths
                                              Model no.            Cable length
                                            4200-TRX-0.3            0.3 meters
                                             4200-TRX-1             1.0 meter
                                             4200-TRX-2             2.0 meters
                                             4200-TRX-3             3.0 meters



                                        Figure 1
                                        Model 4200-TRX-X cable




Electrical specifications
Electrical Impedance: 50
Frequency Range: 0 - 4GHz
Working Voltage:
     Inner Shield to Outer Shield: 250 VDC
     Ctr. Conductor to Outer Shield: 250 VDC
     Ctr. Conductor to Inner Shield: <100V
Insulation Resistance: 1
