                                        Model 4200 MTRX-X Triax Cable Assembly
                                                                   Packing List

Description
The Model 4200-MTRX-X Triax Cable connects the installed Source-Measurement Unit (SMU) in the Model 4200-SCS
(Semiconductor Characterization System) to the device under test (DUT).
Model 4200-MTRX-X (Figure 1) consists of standard triax cable terminated with a miniature male triax connector on one end
and a standard 3-slot male triax connector on the other end.
The miniature triax connector mates to the FORCE connector on the 4210-SMU or 4200-SMU installed in the system. The
standard triax connector connects to the test fixture or probe station holding the DUT.

        CAUTION          The Model 4200-MTRX Triax Cable is intended for connection only to an SMU that
                         does not have a PreAmp installed. NEVER make connection to any miniature triax
                         connector on an SMU if a PreAmp is installed. Otherwise, damage to the SMU
                         and/or the DUT, and/or corrupt data may occur.

The 4200-MTRX-X is available in three lengths. The -X in the model number represents the cable length in meters,
as listed in Table 1.
                                    Table 1
                                    Cable lengths
                                            Model no.              Cable length
                                          4200-MTRX-1                 1 meter
                                          4200-MTRX-2                 2 meters
                                          4200-MTRX-3                 3 meters


                                    Figure 1
                                    Model 4200-MTRX-X cable




Electrical specifications
Electrical Impedance: 50
Frequency Range: 0 - 4GHz
Working Voltage:
     Inner Shield to Outer Shield: 250 VDC
     Ctr. Conductor to Outer Shield: 250 VDC
     Ctr. Conductor to Inner Shield: <100V
Insulation Resistance: 1
