Image preview - the first page of the document



>> Download 2430SweepPulses documenatation <<

Text preview - extract from the document

Is it Possible to Combine Sweep Operation with Pulse Mode on the Model 2430?

It is very much possible to do a Sweep of the Pulses with the Model 2430. It can be
accomplished from either the Front Panel or via bus control (GPIB or RS-232). First, define the
Pulse characteristics (pulse width, pulse delay). Having done this, set up a Sweep by selecting
the Sweep type (linear, log, custom) and configuring the sweep points.
As an example, the scope trace below shows a linear pulse sweep. The Sweep starts at 1 V and
ends at 10 V, with a step size of 1 V. This was set for an Infinite sweep count. In the trigger Model
set the Arm Count for Infinite and the Trigger count for 10.




If selecting the Log sweep type, make sure you do not start the sweep from 0 Volts or 0 Amps as
the logarithm of zero cannot be calculated.

For more information, see section 5 (Pulse Mode) and section 10 (Sweep Operation) in the Model
2400 Series SourceMeter User's Manual.
