Image preview - the first page of the document
2520INT_AN


>> Download 2520INT_AN documenatation <<

Text preview - extract from the document
                                              Number 2418


Application Note                              Making Pulsed Light Measurements with
          Series                              the Model 2520INT Integrating Sphere

                                                                            sphere or to the different device geometries of the germanium
Introduction                                                                and InGaAs detectors tested.
The Model 2520INT integrating sphere is designed for use with
the Model 2520 Pulsed Laser Diode Test System. The sphere's
size (one inch in diameter) and built-in germanium detector were            LIV Measurements
chosen to provide a fast detector rise time (<29ns) and the right           Pulsed LIV (Light-Current-Voltage) laser diode testing is a typi-
amount of input signal attenuation (approximately 100
