Model 8020-SNS-X
Keithley Instruments
28775 Aurora Road
8 Pin to 2 Pin Phoenix Cables
Cleveland, Ohio 44139
1-800-935-5595
http://www.keithley.com
Description
The Keithley Instruments Model 8020-SNS-X 8 Pin to 2 Pin Phoenix Cables are used for connecting 2651A
sense HI and sense LO terminals to the Model 8020. The cable is available in three lengths:
Part number Length
8020-SNS-1 99 cm (39 in.)
8020-SNS-2 200.7 cm (79 in.)
8020-SNS-3 304.8 cm (120 in.)
Figure 1: 8020-SNS-X 8 pin to 2 pin Phoenix cable
